Fireblocks. Installed in wood frame walls, per LF of wall to be blocked. Figures in parentheses indicate
board feet of fire blocking per linear foot of wall, including 10% cutting waste. See also Bridging and
Backing and Nailers.
2" x 3" blocking, Std & Btr
2" x 3" fireblocks, 16" centers, per MBF --@.000 MBF 729.22 -- 729.22
12" OC members (.48 BF per LF) B1@.026 LF 0.35 0.95 1.30
16" OC members (.50 BF per LF) B1@.025 LF 0.36 0.91 1.27
20" OC members (.51 BF per LF) B1@.022 LF 0.37 0.80 1.18
24" OC members (.52 BF per LF) B1@.020 LF 0.38 0.73 1.11
Add for removing and replacing, per block B1@.026 LF -- 0.95 0.95
2" x 4" blocking, Std & Btr
2" x 4" fireblocks, 16" centers, per MBF --@.000 MBF 658.52 -- 658.52
12" OC members (.64 BF per LF) B1@.030 LF 0.42 1.09 1.52
16" OC members (.67 BF per LF) B1@.025 LF 0.44 0.91 1.36
20" OC members (.68 BF per LF) B1@.022 LF 0.44 0.80 1.25
24" OC members (.69 BF per LF) B1@.020 LF 0.45 0.73 1.18
Add to remove and replace, per block B1@.030 LF -- 1.09 1.09
2" x 6" blocking, Std & Btr
2" x 6" fireblocks, 24" centers, per MBF --@.000 MBF 674.68 -- 674.68
12" OC members (.96 BF per LF) B1@.031 LF 0.65 1.13 1.78
16" OC members (1.00 BF per LF) B1@.026 LF 0.68 0.95 1.62
20" OC members (1.02 BF per LF) B1@.022 LF 0.69 0.80 1.49
24" OC members (1.03 BF per LF) B1@.020 LF 0.70 0.73 1.43
Add to remove and replace, per block B1@.034 LF -- 1.24 1.24

Ceiling beams -- room addition. Std & Btr. Installed over wall openings and around floor, ceiling and
roof openings or where a flush beam is called out in the plans, including 10% waste. Don’t use these
cost estimates for door or window headers in framed walls. See the door or window opening framing
assemblies costs that follow.
2" x 6" beams, per MBF B1@24.5 MBF 674.68 893.00 1,567.68
2" x 8" beams, per MBF B1@25.2 MBF 654.48 918.50 1,572.98
2" x 10" beams, per MBF B1@25.1 MBF 678.72 914.90 1,593.62
2" x 12" beams, per MBF B1@25.9 MBF 749.42 944.10 1,693.52
4" x 6" beams, per MBF B1@25.9 MBF 983.74 944.10 1,927.84
4" x 8", 10", 12", 14" beams, per MBF B1@25.5 MBF 983.74 929.50 1,913.24
6" x 6", 8", 10", 12", 14" beams, per MBF B1@19.1 MBF 1,616.00 696.20 2,312.20
2" x 6" (1.10 BF per LF) B1@.028 LF 0.75 1.02 1.77
2" x 8" (1.47 BF per LF) B1@.037 LF 0.96 1.35 2.31
2" x 10" (1.83 BF per LF) B1@.046 LF 1.24 1.68 2.92
2" x 12" (2.20 BF per LF) B1@.057 LF 1.65 2.08 3.72
4" x 8" (2.93 BF per LF) B1@.073 LF 2.88 2.66 5.54
4" x 10" (3.67 BF per LF) B1@.094 LF 3.62 3.43 7.04
4" x 12" (4.40 BF per LF) B1@.112 LF 4.33 4.08 8.41
4" x 14" (5.13 BF per LF) B1@.115 LF 5.05 4.19 9.24
6" x 6" (3.30 BF per LF) B1@.060 LF 5.34 2.19 7.53
6" x 8" (4.40 BF per LF) B1@.080 LF 7.12 2.92 10.04
6" x 10" (5.50 BF per LF) B1@.105 LF 8.91 3.83 12.74
6" x 12" (6.60 BF per LF) B1@.115 LF 10.71 4.19 14.90
6" x 14" (7.70 BF per LF) B1@.120 LF 12.42 4.37 16.80
