Remove and replace exterior wall. Add temporary joist support costs from below. Use 16 linear feet
as the minimum job size. No interior floor finish included.
2" x 4" stud walls with drywall interior, wood siding exterior, 1/2" gypsum drywall inside face ready for
painting, over 3-1/2" R-11 insulation with 5/8" thick rough sawn T-1-11 exterior grade plywood siding on
the outside face
Using 5/8" rough sawn T-1-11 siding at --@.000 MSF 1,030.20 -- 1,030.20
Cost per square foot of wall B1@.108 SF 2.45 3.94 6.39
Cost per running foot, 8' high wall B1@.864 LF 19.70 31.49 51.19
2" x 6" stud walls with drywall interior, wood siding exterior, same construction as above, except with
6-1/4" R-19 insulation.
Cost per square foot of wall B1@.117 SF 2.99 4.27 7.25
Cost per running foot, 8' high wall B1@.936 LF 23.94 34.12 58.06
2" x 4" stud walls with drywall interior, 1/2" gypsum drywall inside face ready for painting, over 3-1/2"
R-11 insulation with .042" vinyl lap siding on the outside face.
Using .042" vinyl lap siding at --@.000 MSF 793.86 -- 793.86
Cost per square foot of wall B1@.112 SF 2.25 4.08 6.33
Cost per running foot, 8' high wall B1@.896 LF 18.43 32.66 51.09
2" x 4" stud walls with drywall interior, 1/2" gypsum drywall on inside face ready for painting, over 3-1/2"
R-11 insulation with 1" x 6" southern yellow pine drop siding, D Grade, 1.19 BF per SF at 5-1/4"
exposure on the outside face.
Using D grade yellow pine drop siding at --@.000 MSF 3,070.40 -- 3,070.40
Cost per square foot of wall B1@.114 SF 4.50 4.16 8.66
Cost per running foot, 8' high wall B1@.912 LF 32.02 33.24 65.26
2" x 6" stud walls with drywall interior, 1" x 6" drop siding exterior, same construction as above, except
with 6-1/4" R-19 insulation
Cost per square foot of wall B1@.123 SF 5.03 4.48 9.51
Cost per running foot, 8' high wall B1@.984 LF 40.30 35.87 76.17
2" x 4" stud walls with drywall interior, stucco exterior, 1/2" gypsum drywall on inside face ready for
painting, over 3-1/2" R-11 insulation and a three-coat exterior plaster (stucco) finish with integral color on
the outside face
Cost per square foot of wall B1@.090 SF 5.33 3.28 8.61
Cost per running foot, 8' high wall B1@.720 LF 42.62 26.24 68.86
2" x 6" stud walls with drywall interior, stucco exterior, same construction as above, except with 6-1/4"
R-19 insulation
Cost per square foot of wall B1@.099 SF 5.03 3.61 8.64
Cost per running foot, 8' high wall B1@.792 LF 40.30 28.87 69.17
Add for other types of gypsum board
1/2" or 5/8" moisture-resistant greenboard
Cost per SF, greenboard per side, add --@.000 SF 0.35 -- 0.35
1/2" or 5/8" moisture-resistant greenboard
Cost per running foot per side 8' high --@.000 LF 2.83 -- 2.83
5/8" thick fire-rated Type X gypsum drywall
Cost per SF, per side, add --@.000 SF 0.05 -- 0.05
5/8" thick fire-rated Type X gypsum drywall
Cost per running foot per side 8' high --@.000 LF 0.40 -- 0.40
Support ceiling joists during replacement of a stud wall, using one 4" x 4" post, 2" x 8" pads and
wedges, 4" x 4" strong back. All materials salvaged. Allow one post per each 5' of wall.
Per support post set and removed B1@.567 Ea -- 20.67 20.67
