HAYWARD D.E. FILTERS

HAYWARD PRO GRID DE FILTERS

• Filter tanks are made from durable glass reinforced co-polymer to meet the demands of the toughest
applications and environmental conditions.
• Heavy-duty, tamper-proof one piece flange clamp securely fastens tank top and
bottom. Allows quick access to all internal components without disturbing piping
or connections.
• High impact grid elements designed for up-flow filtration and top-down backwashing
for maximum efficiency.
ITEM# LIST
Filters Hayward DE2420 24 Sq. Ft. Filter Only H6124 1,181.30 Filters

1,282.80
H6125
Hayward DE3620 36 Sq. Ft. Filter Only
Filters
Hayward DE4820 48 Sq. Ft. Filter Only H6126 1,429.40

Hayward DE6020 60 Sq. Ft. Filter Only H6063 1,593.40

H6125 ProGrid D.E. Filter Guide Performance Data – Filter
PermaGlassXL PermaGlassXL
D.E. Dimensions Filtration Design Turnover (Gallons)
Model # Filtration Area Model #
Required Width Height Area Flow Rate 8 hrs. 10 hrs.
DE2420 24 ft 2 3 lbs. 24" 32½" DE2420 24 ft 2 48 GPM 23,040 28,800
DE3620 36 ft 2 4½ lbs. 24" 34½" DE3620 36 ft 2 72 GPM 34,560 43,200
DE4820 48 ft 2 6 lbs. 24" 40½" DE4820 48 ft 2 96 GPM 46,080 57,600
DE6020 60 ft 2 7½ lbs. 24" 46½" DE6020 60 ft 2 120GPM 57,600 72,000

VALVES FOR PRO GRID DE FILTERS

1½" Vari-Flo Valve Assembly SP0710XR50 H6070 190.20
H6070

2" Vari-Flo Valve Assembly SP0715XR50 H6071 300.50

2" Slide Valve Assembly SP0410X502S H6073 140.40 HAYWARD D.E. FILTERS

2" Selecta-Flo Valve SP0740DE H8018 301.10

H6073
