CABLE CONNECTORS, NON INSULATED

Terminal Insulators - Straight (Additional Products)

Connector Description Art. No. Pack Qty.
Insulating sleeve, transparent PE, for push-on receptacles, plug width 6.3 mm, 0558 180 9
cable gland: 2.5 mm dia.
Insulating sleeve, transparent PE, for flat plugs, plug width 6.3 mm, cable gland:
4.0 x 2.8 mm 0558 181 0
Insulating sleeve, transparent PVC, for female bullet terminals up to 4mm ø - suit 100
Art. No. 0558 505 1 , 0558 930 0558 170 8
Insulating sleeve, transparent PVC, for male bullet terminals up to 4mm ø- suit Art.
No. 0558 513 3 , 0558 530 8 0558 179 1

Spade Terminal, Straight/Angled, Tabs (male)
Connector mm² Pin Width / Material Surface Coating Art. No. Pack Qty.
Dia. Ø (mm)
5.2 Brass 0558 160 61
CuZn 50/100
Pin:Cu
2 x 6.3 x 0.8 5.2 Sn (tinned) 0558 193 5

Ring Lugs
Connector mm² Flange hole ø (mm) Material Surface Coating Art. No. Pack Qty.
M4 0558 521 5
M5 0558 521 7
1.5 - 2.5 CuZn Brass 100
M6 0558 521 9
M8 0558 522 1

Legend

Abr. Description
Cu Copper
Sn Tin
Ni Nickel
CuSn Copper/Tin alloy
CuZn Copper/Zinc alloy
CuAl Copper/Aluminium alloy
