05-30 VEHICLE MAINTENNANCE - CHECK

CHECK BRAKING SYSTEM

NOTICE

• Only use the braking fluid authorized by Foton.
• Do not mix the braking fluid with other liquid, or it may damage the braking
system and affect the driving.
• Determine whether topping is necessary depending on the tear and wear of the
brake lining.
05

1 . Open the engine hood.
2 . Check braking fluid tank level:
(a) When the brake lining is extremely worn, the level should be close to the minimum
level.
(b) When the brake lining is hardly worn, the level should be close to the maximum level.
3 . Check for damage and leakage in the following parts:
(a) Brake pump
(b) Servo brake
(c) Brake calipers
(d) Brake pipe
4 . Check whether the gap between the brake hose and the body is correct, whether
there is any scratch on the brake hose and whether the connection and fitting
of the brake pipe are secured.
