VEHICLE MAINTENNANCE - CHECK 05-33

CHECK TIRE

NOTICE
When it is found that the tire is worn to its extreme or so damaged that it affects driving
safety, it is necessary to inform the customer and suggest replacement.

1 . Check for damage and impurity on the rolling surface and side wall of the tire
as well as hole, cut and piercing on the wall.
2 . Check whether the rolling surface is seriously worn in one side, and if yes,
05
perform wheel alignment.

3 . Check the tread depth (including spare
tire) and ensure the depth is greater than
that of the wear indicator and the side wear
indicator hasn't been fully worn.

Max. tread depth: 1.6mm

4 . Check and adjust the tire pressure (including spare tire):

Front tire Rear tire Spare tire
P245/70 R16 220kPa 240kPa 260kPa

P265/70 R16 220kPa 240kPa 260kPa
P265/65 R17 220kPa 240kPa 260kPa
