71-6 WIRING - INTRODUCTION TO CIRCUITS

NO. Name Description
System names are designed to distinguish different sys-
10 System name
tems and functions, which can be easily found.

Describe the value and operation status of the electrical
11 Repair instructions
components for reference during troubleshooting.

Indicates the harness page to be referred to (the position
12 component position of the electrical component in the vehicle and the harness
alignment).

Indicate the harness page (the harness with the female
connector between
13 connector is in the front, while the harness with male one
wiring harnesses
in the back) to be referred to.
Indicates the reference vehicle position for the connecting
14 Earthing point between the electrical component's return wire and
71
the metal part of the vehicle.
