WINDSHIELD - FRONT WINDSCREEN 82-31

REPLACEMENT

1 . Remove the engine hood. (Refer to "Chapter 87. Door/engine hood - engine
hood, replacement")
2 . Remove the front wiper arm assembly. (Refer to "Chapter 65. Wiper & washer -
wiper assembly, replacement")
3 . Remove the lower windscreen trim. (Refer to "Chapter 65. Wiper & washer -
wiper linkage assembly, replacement")
4 . Remove the rearview mirror. (Refer to "Chapter 82.Windscreen/window/rearview
mirror - rearview mirror, replacement")
5 . Remove the A column upper panel. (Refer to "Chapter 88. Interior & exterior
trims - side skirts, replacement")

6 . Remove the windscreen.

(a) Remove the seal with a special tool.
(b) Mark the windscreen and the body as
illustrated.

NOTICE

If the windscreen is not intended to reuse, no
mark is necessary. 82

(c) Pass a thin wire through between the body
and the glass and tie the two ends of the wire
on wood or equivalent.
(d) Pull the wire around the windscreen to remove
the adhesive.
NOTICE

When separating the windscreen, be careful not
to damage the paint or interior or exterior trims.
In order not to scratch the dashboard when
removing the windscreen, place a piece of plastic
sheet between the wire and the dashboard.

(e) Remove the windscreen assembly with
sucker.

NOTICE

Be careful not to drop the windscreen. When
removing the windscreen, leave as much
adhesive as possible on the body.
