83-34 INSTRUMENT PANEL - COMBINATION INSTRUMENT

Defect Suspect Area Reference
Chapter 4. Diagnostics -
1. Fuel sensor instrument panel, fuel gauge
defect
Chapter 4. Diagnostics -
Faulty fuel gauge 2. Fuel gauge power supply instrument panel, fuel gauge
defect
Chapter 4. Diagnostics -
3. Fuel gauge instrument panel, fuel gauge
defect

Warning Lamp

Defect Suspect Area Reference
Chapter 4. Diagnostics -
engine control system, fault
1. Engine electric control code list
system Chapter 4. Diagnostics -
diesel engine control system,
fault code list
83
Chapter 4. Diagnostics -
engine control system, fault
Engine warning lamp always code list
2. Engine warning lamp circuit
out/on Chapter 4. Diagnostics -
diesel engine control system,
fault code list

Chapter 4. Diagnostics -
engine control system, fault
code list
3. Instrument panel assembly
Chapter 4. Diagnostics -
diesel engine control system,
fault code list

Chapter 4. Diagnostics -
1. Brake warning switch instrument panel, brake
warning light always out/on
Chapter 4. Diagnostics -
Brake warning lamp always
2. Brake warning lamp circuit instrument panel, brake
out/on
warning light always out/on
Chapter 4. Diagnostics -
3. Instrument panel assembly instrument panel, brake
warning light always out/on
ABS warning lamp always 1. ABS system defect Chapter 4. Diagnostics - ABS
out/on system, defects
