J.49 Work in cast stone

Work in cast stone shall be given in accordance with the rules for natural stonework in clause
J.3-35.

Clayware work

J.50 Generally

1. Clayware work shall consist of blocks of fired clayware cast to given dimensions and used
in a similar manner and for the same purpose as natUrai stone.

2. Particulars of the following shall be given:

a Kind of clayware.
b Any requirements as to the coloUr.
c. Texture and finish to exposed faces of blocks (e,g. natural, rough dnessed or
hammer dressed).
d. Composition and mix of mortar for bedding, jointing and pointing.
e. Method of pointing.
f Any requirements as to cleaning the finished work on completion.

3. Moulds necessary to produce biocks of the required size and shape shali be deemed to
be included with the items.

4. Blocks required to be cast hollow and filled with concrete shall be so described stating the
composition and mix of the concrete. Formwork shall be deemed to be included with the
items.

J.51 Work in clayware

Work in clayware shall be given in accordance with the rules for natural stonework in clauses
J.3-35.

Sundries

J.52 Grooves for waterbars, flashings and skirtings

1. Grooves for waterbars and the like shall be given in metres.

2. Grooves for turned-in edges of flashings and for nibs of skirtings shall each be given
separately in metres. No distinction shall be made between horizontal, raking, vertical and
curved grooves. Pointing the grooves and dressing the face of masonry or rubble work to
receive flashings and skirtings shall be given in the description

J.53 Chases

Chases shall be given in metres stating the size, the kind of masonry or rubble walling and the
finish to back and sides of chase. No distinction shall be made between horizontal, raking,
vertical and curved chases. No deduction of masonry or rubble work shali be made for any
chase.

J.54 Cramps

Metal cramps, slate dowels, metal dowels, lead plugs and the like shall each be enumerated
separately stating the size Mortices and running with lead or mortar shall be given in the
description stating the kind of masonry or rubble walling.

64
