J.18 Lintels, sills, mullions and transoms

1. Lintels, sills, mullions and transoms shall each be given separately in metres stating the
size and profile.

2. Ends and stoolings shall each be enumerated separately as extra over the member on
which they occur.

J.19 Copings, cornices and band courses

1. Copings, cornices and band-courses, string courses, plinth-cappings and the like
members shall each be given separately in metres stating the size and profile. Horizontal,
raking and vertical members shall each be so described. Fair ends, returned ends and the
like shall be deemed to be included.

2. Kneeler-blocks, bonder blocks, apex~blocks, angle blocks, stooling-blocks and any end-
blocks which involve the use of stones thicker than the member in which they occur shall
each be enumerated separately stating the size and profile.

3. Plain band-courses over 300mm wide shall be dealt with as walling or facework.

J.20 Slab architraves and surrounds to openings

1. Slab architraves and slab surrounds to openings (i.e. slabs not bonded to surrounding
work) shall be given separately in metres stating the size and profile. Ends and angles
shall be deemed to be included with the items.

2. Plinth-blocks, angle-blocks, key-blocks and the like shall each be enUmerated separately
stating the size and profile.

J.21 Arches

Springers, voussoirs and keystones of arches shall each be enumerated separately stating the
size and profile of the stone and the type of arch. Projecting members of arches shall be so
described stating the size and profile.

J.22 Tumblings to buttresses

Tumbling to buttresses shall be enUmerated stating the size and profile.

J.23 Pier~caps and chimney-caps

Pier-caps, chimney-caps and the like shall each be enUmerated separately stating the size and
profile Openings in chimney~caps shall be given in the description.

J.24 Finials, brackets and corbels

Finials, terminals, brackets, corbels and the like shall each be enUmerated separately stating
the size and profile.

J.25 Tracery

Stones forming tracery shall be enumerated stating the size and profile.

59
