STT

Ambient air boot dryer rack

Solid stainless-steel tubular frame construction
Wall-mounting or floor stand
Capacity: 10, 15, 20, 30, 40, 60 pairs of boots
Boot holder bracket made of stainless-steel tubing
Air nozzle integrated in bracket
Warm air recirculated via 1 hot-air fan
Disinfection via built-in UV lamp

Dimensions:
Type Mounting Boot Capacity (pairs) Dimensions W x D x H (mm)
STT-W 10 wall 10 540 x 500 x 1960
STT-W 15 wall 15 773 x 410 x 1960
STT-W 20 wall 20 1046 x 410 x 1960
STT-W 30 wall 30 1546 x 410 x 1960
STT-S 10 stand 10 540 x 500 x 1980
STT-S 15 stand 15 790 x 500 x 1980
STT-S 20 stand 20 1040 x 500 x 1980
STT-S 30 stand 30 1540 x 500 x 1980
STT-S 2×20 stand – two sides 40 1040 x 500 x 1980
STT-S 2×30 stand – two sides 60 1540 x 850 x 1980

Specifications:
Power supply 240 VAC 60 Hz
Performance 1, ,5 kW3 kW (depending on the model)
Power consumption UV lamp: 1x 8 W, 2x 8W (depending on the model)
Nominal power 2x 230V, 4x 230 V – 037/0.5A – 83/110W (fan)
Heating power 2x 600 W, 4x 600 W (depending on the model)

Optional Items:
Numbering
