DILUTE PHASE
PNEUMATIC CONVEYING PRESSURE SYSTEM VACUUM SYSTEM
Features: Features:
Transfer Dry Bulk Solid Materials Efficiently & Cost Effectivly BIN VENT FILTERS • Single Pick-Up Area • Multiple Pick-Up Points
Dilute phase conveying systems offer a long-lasting, trouble-free • Multiple Destinations BIN VENT FILTERS • Common Destination
alternative to mechanical conveying systems, such as screw STORAGE • Inherent Dust Control
conveyors, belt conveyors, vibratory conveyors, aeromechanical SILOS
conveyors or bucket elevators. The advantages include: SLIDE DIVERTER VACUUM FILTER VACUUM
BREAKER
RECEIVER
HOPPER TOP VALVES VALVE INLET FILTER
PRESSURE FILTER
RECEIVER
System Types: PACKAGE AIRLOCK
BLOWER
• Pressure System KNIFE SLIDE DIVERTER
GATES
• Vacuum System LOAD CELLS SCALE VALVE BUTTERFLY LOAD
CELLS
VALVE
• Vacuum/Pressure Combination HOPPER INLET FILTER
CUSTOMER
INLET FILTER
ROTARY PROCESS
Benefits of Dilute Phase VENTED INLET AIRLOCK
HOPPER
• Easier to install and more flexibility in routing CUSTOMER SYSTEM BAG DUMP WITH
CONTROLS
• Lower maintenance PROCESS IBC2000 BULK INTEGRAL FILTER
BAG UNLOADER
• Easier to route, especially over longer distances VACUUM
• Easier to clean IBC3000 BULK PACKAGE
BLOWER
BAG FILLER
• Self-contained with less emissions in many cases
• Easier to expand in the future
BASICS OF DILUTE PHASE CONVEYING VACUUM/PRESSURE COMBO
Magnum Systems’ knowledge of products/materials and Material to Air Metering Device
broad range of dilute phase systems and components A material to air metering device may be something as Features:
put the right equipment in place, whether your building simple as a material feeder such as a rotary valve, screw • Multiple Pick-Up Points SLIDE DIVERTER
one from scratch, reconfiguring or repairing. Our conveyor or vibratory feeder, or as complex as an air inlet to Multiple Destinations
engineers know the components and their properties by management system. • Installed for Unloading Rail BIN VENT FILTER
heart. cars and Hopper Trucks VACUUM
BREAKER
Material to Air Separation Device
Air Generation Device A material and air separation device is usually a pulse- FILTER RECEIVER
An air generation device is a positive displacement jet fabric bag house of some sort. This may be felt or STORAGE
SILOS
blower, but occasionally a fan, regenerative blower or spun bound polyester, square or round, stand alone or
compressor. in the form of a bin vent. Other less common means of
separation and filtration include such items as cyclones.
Airlock Valve LEVEL INDICATORS
An airlock is most commonly a rotary valve, but can also Conveyance Medium
be referred to as a butterfly valve, flapper/dump valve, A conveyance medium, typically tubing, piping or hose.
knife gate, venture, or other device. Airlocks need to RAILCAR DISCHARGE
ADAPTER
be located at the inlet of a pressure system and the PRESSURE
discharge of a vacuum system. BLOWER
PACKAGE VACUUM
BLOWER BIN
PACKAGE ACTIVATORS
