TUBING, SANITARY
Sale Technical Sheet
69 William Street, Belleville, NJ 07109 STS Number ________
PH: 973-759-4600 * Fax: 973-759-6449 Effective Date _______
EMAIL: info@vac-u-max.com Supersedes _________
WEB SITE: www.vac-u-max.com
B. TUBE SANITARY 304 & 316 SS STRAIGHT LENGTHS
Description:
Tube, _________” OD tube size x .065 wall thickness x 10' long, constructed of 304 SS, polished 150
grit inside and outside.
a. Without Ferrules
b. With one ferrule and one plain end
c. With two ferrule ends

TUBE W/O FERRULES W/1 FERRULE W/2 FERRULES
OD
304 316 304 316 304 316
1.5 21386 23276 21430 23300 21395 23305
2.0 21387 23277 21391 23301 21396 23306
2.5 21388 23278 21392 23302 21397 23307
3.0 21389 23279 21393 23303 21398 23308
4.0 21390 23280 21394 23304 21300 23309

The 304 Sanitary Tubing of this section is found in Price List Class PV
The 316 Sanitary Tubing of this section is found in Price List Class KJ

C. POLYCARBONATE TUBING, SWEEPS, AND SLEEVES
It’s a clear, rigid, transparent thermoplastic that’s extruded from Tenite butyrate, a cellulose-
acetate butyrate compound.

PART NUMBER DESCRIPTION (GROUP 1) REF DWG
POLYCARBONATE TUBING SCB03035R00
23511 Tube, 4" OD x .187 wall 3/16" (.187) X 10 FT SCB03035R00
Tube, 5" OD X 5 5/8" ID 3/16" (.187) Wall X 20 FT SCB03035R00
23513 Tube, 6” OD X 5 5/8” ID 3/16” (.187) Wall X 20 FT SCB03035R00
68375 Tube, 8” OD X 7 5/8” ID 3/16” (.187) Wall X 20 FT SCB03035R00
POLYCARBONATE SWEEP
23506 EL, 3" OD X 90° X 2-5/8" ID X 36 CLR X 6" Tangents SCB03035R00
23507 EL, 4" OD X 90° X 3-5/8" ID X 48 CLR X 6" Tangents SCB03035R00
23508 EL, 5" OD X 90° X 4-5/8" ID X 60 CLR X 6" Tangents SCB03035R00
23509 EL, 6" OD X 90° X 5 5/8" ID X 60 CLR X 6" Tangents SCB03035R00
23509X24CLR EL, TUBE 6" X 90° X 5 5/8" ID X 24 CLR X 6" Tangents SCB03035R00
23509X36CLR EL, TUBE 6" X 90° X 5 5/8" ID X 36 CLR X 6" Tangents SCB03035R00
23509X36CLRX45 EL, TUBE 6 X 45° X 5 5/8" ID X 36 CLR X 6" Tangents SCB03035R00
EL, TUBE 8" OD X 90° X 7 5/8" ID X 60" CLR X 6" Tangents SCB03035R00
68376X36CLR EL, TUBE 8 X 45° X 7 5/8" ID X 36 CLR X 6" Tangents SCB03035R00
68377X36CLR EL, TUBE 8 X 90° X 7 5/8" ID X 36 CLR X 6" Tangents SCB03035R00
POLYCARBONATE SLEEVE
Sleeve ID X 6” Long

PAGE 11
FOR REFERENCE ONLY
