ELECTRICAL

SC 100 LINK HARNESSES 84-880756T 3
3 ft. (.9 meters) SmartCraft Extension Harness
Provides data link extension between SC100 Series products.
SYSTEM LINK ADAPTER KIT
84-880756B 3
3 ft. (.9 meters) SmartCraft Extension Harness
Provides data link extension between SC100 Series products.
Priced individually, sold @ multiples of 12
84-880756T10
10 ft. (3.0 meters) SmartCraft Extension Harness
Provides data link extension between SC100 Series products.
84-880756T30
30 ft. (9.1 meters) SmartCraft Extension Harness
Provides data link extension between SC100 Series products.
84-880756B30
84-8M0052774 30 ft. (9.1 meters) SmartCraft Extension Harness
Kit that drives SC100 Link Gauges from 10 Pin connection at the helm. Contains Provides data link extension between SC100 Series products.
10 pin to 3 pin adapter and 3 pin to 3 pin low voltage reset module. Priced individually, sold @ multiples of 12
Engine must be capable of providing Tach Link output and gray analog tach wire
must be populated in 10 pin connection at helm in order to utilize this kit. INSTRUMENT HARNESSES
SYSTEM LINK RESET HARNESS
Harnesses have ring terminal leads bundled for each gauge.

IGNITION HARNESS - NON DTS 14 PIN

898289T42
Resets SC 100 gauges in the event of voltage drops due to starting engine with a
low/weak battery. Use in conjunction with System Link Harness (84‑892821K01)
SmartCraft SC 100 gauges
84-896537T02
SC 100 DATA HARNESS 2 ft. harness (896537A02) with new 14 pin connector for the engine and additional
connectors that allow easy quick connect solutions to the rigging process. Loose
harness.
Analog gauges also require the use of harness 84‑892990T01, T10 or T15.
2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors
84-896537T08
ELECTRICAL connectors that allow easy quick connect solutions to the rigging process. Loose
8 ft. harness (896537A08) with new 14 pin connector for the engine and additional
harness.
Analog gauges also require the use of harness 84‑892990T01, T10 or T15.
2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors
84-896537T11
84-880756T05 11 ft. harness (896537A11) with new 14 pin connector for the engine and
6 in. SmartCraft Extension Harness additional connectors that allow easy quick connect solutions to the rigging
Provides data link extension between SC100 Series products. process. Loose harness.
Analog gauges also require the use of harness 84‑892990T01, T10 or T15.
SC 100 DATA HARNESS 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors
84-896537T15
15 ft. harness (896537A15) with new 14 pin connector for the engine and
additional connectors that allow easy quick connect solutions to the rigging
process. Loose harness.
Analog gauges also require the use of harness 84‑892990T01, T10 or T15.
2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors
84-896537T20
20 ft. harness (896537A20) with new 14 pin connector for the engine and
additional connectors that allow easy quick connect solutions to the rigging
process. Loose harness.
Analog gauges also require the use of harness 84‑892990T01, T10 or T15.
84-880756T 1
1 ft. (.3 meters) SmartCraft Extension Harness 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors
Provides data link extension between SC100 Series products.
572 2019 Quicksilver Precision Parts & Accessories Guide
