ELECTRICAL

INSTRUMENT EXTENSION HARNESSES (GAS INSTRUMENT EXTENSION HARNESSES (DIESEL)
ENGINES)
All 1994‑2000 MCM/MIE diesel models (except D‑Tronic models)
require both an 8 lead and a 9 lead extension harness to connect
Fits 1986 and newer MCM/MIE gasoline engines. instumentation to the engine.
3.4L/4.6L REPOWER HARNESS KIT EXTENSION HARNESS

84-8M0145987 84- 17829A10
Make easy work of repowering that Oprtimax or Verado to the newer 3.4L V6 or 10 ft.(3.05 m) harness, 8 lead harness.
4.6L V8 Fourstroke engines. Kit contains a wide variety of harnesses: 4 pin depth Used as harness extension or to complete two station installations.
extension harness, 2 pin clean power extension harness, 2 pin WIF extension
harness, 6 pin fuel/paddle extension harness, 14 pin data cable extension harness, 84- 17829A20
10 pin blue data cable extension harness, 3 pin power steering extension harness 20 ft.(6.1 m) harness, 8 lead harness.
and 10 pin male to male gender bender harness Used as harness extension or to complete two station installations.
Repower harness kit has a wide variety of harnesses that makes repowering an
exisiting Optimax or Verado application with the 3.4L V6 or 4.6L V8 Fourstroke INSTRUMENT EXTENSION HARNESS
engine easy
INSTRUMENT EXTENSION HARNESS

84-812441A10
10 ft.(3.05 m) harness, 9 lead harness.
Used as harness extension or to complete two station installations.
84-812441A10
10 ft.(3.05 m) harness, 9 lead harness. 84-812441A15
Used as harness extension or to complete two station installations. 15 ft.(4.57 m) harness, 9 lead harness.
Used as harness extension or to complete two station installations.
84-812441A15
15 ft.(4.57 m) harness, 9 lead harness. 84-812441A20
Used as harness extension or to complete two station installations. 20 ft.(6.1 m) harness, 9 lead harness. ELECTRICAL
Used as harness extension or to complete two station installations.
84-812441A20
20 ft.(6.1 m) harness, 9 lead harness. INSTRUMENT EXTENSION HARNESS
Used as harness extension or to complete two station installations.
84-812835A30
30 ft.(9.14 m) harness, 9 lead harness.
Used as harness extension or to complete two station installations.
84-812835A45
45 ft.(13.72 m) harness, 9 lead harness.
Used as harness extension or to complete two station installations.

84-855390
20 ft.(6 m) harness
Fits (1997‑2000) D2.8L and D4.2L Electronic diesel models

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 575
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
