STEERING

MERCURY HYD BOLT-ON STEERING KIT- STD -W/O NON VENTED CAP
HOSES

19-898432
898349A02 Required for dual station installations of steering system.
This kit includes a standard helm (1.5Cu Inch) with all the needed components to
install the helm along with a bolt‑on cylinder with hardware . This bolt‑on kit is the REMOTE FILL KIT FOR HYDRAULIC STEERING
most robust hydraulic system in the market. The cylinder was tested to all Verado
standards for load and strength. The kit also includes high strength machined
stainless steel screws that are used at each attachment point. Order Verado hoses
897982K__ series separately
Used on all Verado 135‑200 L4 engines, 75‑115 4 Cylinder 4 strokes , OptiMax
1/5L and V6 engines ( order arm 898082A03 when used on 1.5L Opti) (Use with
Power Steering Hoses 8M0046914 thru 8M00469932)
MERCURY HYD BOLT-ON STEERING KIT-TILT -W/O
HOSES

64-889934A05
Remote fill adapter for rear mount and tilt mount Hydraulic pumps
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
HYDRAULIC HELM STEERING FLUID

898349A03
This kit includes a Tilt helm (1.5 Cu Inch) with all the needed components to install
the helm along with a bolt‑on cylinder with hardware and remote fill kit. This
bolt‑on kit is the most robust hydraulic system in the market. The cylinder was
tested to all Verado standards for load and strength. The kit also includes high
strength machined stainless steel screws that are used at each attachment point.
Order Verado hoses (897982K__) separately
Used on all Verado 135‑200 L4 engines, 75‑115 4 Cylinder 4 strokes , OptiMax
1/5L and V6 engines ( order arm 898082A03 when used on 1.5L Opti) (Use with
Power Steering Hoses 8M0046914 thru 8M00469932)
92-858078QB1
VENTED HELM CAP-VCAP For use in MCM compact hydraulic helm steering systems.
Also used on Mercury Hydraulic Steering ‑ Verado 135‑175 and bolt‑on steering
system.
1 L (33.8 fl oz) plastic bottle
Quicksilver Branded
HYDRAULIC STEERING ARM

64-891667Q01
VCAP Vented helm cap for use on Q/S helms 891665Q02 and 891666Q01

898082A03
This arm attaches the cylinder to the engine for 1.5L OptiMax engines. Remove
existing arm on 898349A01 cylinder and replace it with this arm for proper STEERING
clearances
1.5L OptiMax engines

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 655
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
