Page 657 - Quicksilver Accesories Guide 2019

STEERING

32-8M0053479 32-8M0053491
New high strength 1500 PSI hose with compression type fittings. Fittings are made New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (7 ft) of brass with a nickel plating for extra corrision resistance. (30 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms 8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144 8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053480 32-8M0053492
New high strength 1500 PSI hose with compression type fittings. Fittings are made New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. ( 8 ft) of brass with a nickel plating for extra corrision resistance. (32 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms 8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144 8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053481 VENTED HELM CAP-VCAP
New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (10 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053482
New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (12 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053483
New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (14 ft) 64-891667Q01
Used with 8M0054993/8M0056619 Basic Cylinders as well as the VCAP Vented helm cap for use on Q/S helms 891665Q02 and 891666Q01
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144 NON VENTED CAP
32-8M0053484
New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (16 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053485
New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (18 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053486 19-898432
New high strength 1500 PSI hose with compression type fittings. Fittings are made Required for dual station installations of steering system.
of brass with a nickel plating for extra corrision resistance. (20 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the REMOTE FILL KIT FOR HYDRAULIC STEERING
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053487
New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (22 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053488
New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (24 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms 64-889934A05
8M0050098/8M0050099 and 8M0056139 thru 8M0056144 Remote fill adapter for rear mount and tilt mount Hydraulic pumps
32-8M0053489 Hydraulic Steering for Verado 135 to 200‑4 stroke engines
New high strength 1500 PSI hose with compression type fittings. Fittings are made Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
of brass with a nickel plating for extra corrision resistance. (26 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053490
New high strength 1500 PSI hose with compression type fittings. Fittings are made
STEERING Used with 8M0054993/8M0056619 Basic Cylinders as well as the
of brass with a nickel plating for extra corrision resistance. (28 ft)
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144

650 2019 Quicksilver Precision Parts & Accessories Guide
