STEERING

175HP+ KICKER ELECTRICAL KIT HYDRAULIC HELM - BASIC SYSTEM

8M0149838
This system allows you to run your kicker engine and use the power steering
system without your primary engine running. This system allows you to connect to
a deep cell battery (not your starter battery) and the system will provide normal
power steering from the wheel. The system will alert you when your auxiliary
battery is below 9.5 volts. This signal means that you must start your primary
engine to change the battery system. This kit will save the starting battery for
primary starting use only. Must select the appropriate isolator to be paired with this
system, dependent on engine configuration. 8M0050098
175hp+ power steering systems with a kicker engine. 200‑350 Verado 2015 (Gen This hydraulic helm is a std 20 CC / 1.2 Cu Inch helm with compression style
5) and newer and all 175‑300hp 3.4L and 4.6L engines.
fittings. It is used with the 8M0054993 Basic cylinder. The shaft is anodized steel
with a composite tank. The pressure relief is 1000 PSI for high torque
HYDRAULIC STEERING - BASIC AND HEAVY DUTY applicactions for improved performance. (5.2 Lock to lock wheel turns).
SYSTEMS Single engine 75‑150 HP ( includes new 150 HP 4 Stroke)
HYDRAULIC HELM - BASIC SYSTEM
Both the Basic and the Heavy Duty Hydraulic Systems in this section
will use the hoses listed. (8M0053474 to 8M0053492) Note that the
Basic is for single engines only ‑ 150 HP and below. The Heavy Duty
systems are for single engines above 150 HP as well as multiple
engines. Fittings are listed in this section that can be installed to the
compression style connections.
CYLINDER - HYDRAULIC - STANDARD

8M0050099
This hydraulic helm is a Tilt 20 CC / 1.2 Cu Inch helm with compression style
fittings. It is used with the 8M0054993 Basic cylinder. The shaft is anodized steel
8M0141911 with a composite tank. The pressure relief is 1000 PSI for high torque
This Basic hydraulic cylinder has the same robust performance design requirement applicactions for improved performance. (5.2 Lock to lock wheel turns).
as our heavy duty cylinder. It is qualified to the same 300,000 cycle as our other Single engine 75‑150 HP OB (Includes new 150 HP 4 stroke)
steering systems, has high strength fasteners, stainless steel arm, heavy duty triple
seal cartridges for enhanced duribilty and longevity high quality fittings using HYDRAULIC HELM AND CYLINDER- SMALL- STD W-O
swaged compression style hose connections. HOSES
All Single Outboard ‑ 150 HP and below
(1.5L Opti engine requires the special arm ‑ cylinder 8M0056619)
CYLINDER - HYDRAULIC - STANDARD

8M0077699
This kit includes a small cylinder and a new 1.2 Cubic Inch (20cc) Standard Helm.
They do not come with hoses, you will need to order Compression Style fitting
hoses 8M0053474 thru 8M0053491 hose kits (1000 PSI relief).
8M0056619 Used on any brand Single Engine Outboard 150 HP and below
This Basic hydraulic cylinder has the same robust performance design requirement
as our heavy duty cylinder. It is qualified to the same 300,000 cycle as our other
steering systems, has high strength fasteners, stainless steel arm, with a special
bend for clearance, heavy duty triple seal cartridges for enhanced duribilty and
longevity. High quality fittings using swaged compression style hose connections.
Mercury OB ‑ 1.5L OptiMax
