STEERING

HYDRAULIC HELM AND CYLINDER- SMALL- TILT W-O HYDRAULIC HELM PUMP - COMPRESSION STYLE
HOSES FITTINGS

8M0077701 8M0056139
This kit includes a small cylinder and a new 1.2 Cubic Inch (20cc) Tilt Helm. They Front Mount Standard helm ‑ 1.5 cu in (25 CC.) displacement. Approximately 5
do not come with hoses, you will need to order Compression Style fitting hoses turns lock to lock on singles (Use Compression style fittings and hoses)
8M0053474 thru 8M0053491 hose kits (1000 PSI relief). and 8 on dual cylinders
Used on any brand Single Engine Outboard 150 HP and below Compact design
Built‑in valve for positive rudder lock
CYLINDER WITH COMPRESSION STYLE FITTINGS Integral relief valve for over pressure protection‑ 1500 PSI
Use with cylinder 8M0050097 and hoses 8M0053474 thru 8M0053492. Use on
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
steering installation.
8M0056140
Front Mount Tilt helm ‑ 1.5 cu in (25 CC.) displacement. Approximately 5 turns
lock to lock on singles
and 8 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection ‑ 1500 PSI (Use
Compression style fittings and hoses)
Use with cylinder 8M0050097 and hoses 8M0053474 thru 8M0053492. Use on
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
8M0050097 steering installation.
Heavy Duty Hydraulic standard cylinder that uses compression hoses 8M0053474 8M0056141
‑ 8M005053491. This cylinder is tested to Mercury's rigid standards that include Front Mount Standard helm ‑ 2.0 cu in (33CC.) displacement. Approximately 4.7
higher loads and cycle testing to 300,000 cycles. It includes machined, high turns lock to lock on singles
strength fasteners, electro polished SS arm, and heavy duty triple seal cartridges and 7.3 on dual cylinders
for enhanced duribility and longevity Compact design
135‑300 HP OPTI Max Outboards and 4 Cylinder Verado (Hydraulic only) Use on Built‑in valve for positive rudder lock
single, dual and triple installations Integral relief valve for over pressure protection ‑ 1500 PSI (Use
Compression style fittings and hoses)
CYLINDER WITH COMPRESSION STYLE FITTINGS- Use with cylinder 8M0050097 and hoses 8M0053474 thru 8M0053492. Use on
PORT single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
steering installation.
8M0056142
Front Mount Tilt helm ‑ 2.0 cu in (33 CC.) displacement. Approximately 4.7 turns
lock to lock on singles
and 7.3 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection ‑ 1500 PSI (Use
Compression style fittings and hoses)
Use with cylinder 8M0050097 and hoses 8M0053474 thru 8M0053492. Use on
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
steering installation.

8M0056145
Heavy Duty Hydraulic cylinder counter rotation that uses compression hoses
8M0053474 ‑ 8M005053491. This cylinder is tested to Mercury's rigid standards
that include higher loads and cycle testing to 300,000 cycles. It includes machined,
high strength fasteners, electro polished SS arm, and heavy duty triple seal
cartridges for enhanced duribility and longevity
135‑300 HP OPTI Max Outboards and 4 Cylinder Verado (Hydraulic only) Use on
dual and triple installations (Counter rotation )

STEERING
