Page 650 - Quicksilver Accesories Guide 2019

STEERING

UNION FITTING MALE TO MALE 11/16 IN.
POWER STEERING HOSE KITS-JOYSTICK
PILOTING

JOYSTICK PILOTING STEERING HOSES

22-892527
Union Fitting Male to Male 11/16 in. Power Steering Fittings‑ to connect 2 pressure
hoses end to end
ELBOW FITTING FEMALE 9/16 IN.
32-8M0078210
Kit includes two hoses of the same length (10 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
JOYSTICK PILOTING HOSES
32-8M0078211
Kit includes two hoses of the same length (12 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0078212
Kit includes two hoses of the same length (14 ft) for use on Joystick Piloting. The
22-892528 hoses will route from the pump to the bulk head fitting.
Elbow Fitting Female to Male 9/16 in.. Power Steering Fittings to allow 90 degree Can be used on Verado 250‑350 HP and 400R Joystick installations.
connection at helm (R&L port)
Verado Engines ‑ 135 to 300 HP Power Steering 32-8M0078213
Kit includes two hoses of the same length (16 ft) for use on Joystick Piloting. The
FITTING KIT BULKHEAD hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0078214
Kit includes two hoses of the same length (18 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0078215
Kit includes two hoses of the same length (20 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0078216
Kit includes two hoses of the same length (22 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
64-8M0088973 Can be used on Verado 250‑350 HP and 400R Joystick installations.
Improved bulkhead fitting kit with chrome housing for multiple hose installations.
Multiple Hose Installations for Compression style hoses. 32-8M0078217
Kit includes two hoses of the same length (24 ft) for use on Joystick Piloting. The
ELBOW- FEMALE TO MALE hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0032520
Kit includes two hoses of same length (26 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0032530
Kit includes two hoses of the same length (28 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0032547
Kit includes two hoses of the same length (30 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
22-897726 Can be used on Verado 250‑350 HP and 400R Joystick installations.
Female to Male .6875 Inch (11/16)
Power Steering Fittings‑ To allow 90 degree connection at helm (R&L port) 32-8M0032630
Power Steering Fittings Kit includes two hoses of the same length (32 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting. STEERING
Can be used on Verado 250‑350 HP and 400R Joystick installations.

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 643
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
