STEERING

HOSE CONNECTION KIT
UFLEX STEERING CYLINDERS, HELMS AND
HOSES- MISC

HYDRAULIC HOSE - COMPRESSION STYLE FITTINGS

64-826498A 1
Connects 3/8 in.(9.5mm) diameter copper tubing to SeaStar Cylinders (using
SeaStar Outboard Hoses)
FRONT PIVOT MOUNT CYLINDER CHART 32-8M0053483
New high strength 1500 PSI hose with compression type fittings. Fittings are made
Front Pivot Mount Outboard Cylinder of brass with a nickel plating for extra corrision resistance. (14 ft)
Used with 8M0054993/8M0056619 Basic Cylinders as well as the
See Teleflex application guide for additional Information 8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144
Brand Year Range Model Front Pivot 32-8M0053484
Mount O/B New high strength 1500 PSI hose with compression type fittings. Fittings are made
Cylinder of brass with a nickel plating for extra corrision resistance. (16 ft)
Honda 1996 - 2019 75-90 HP 64-804378A 1 Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
Honda 1998 - 2019 30-50 HP 64-804378A 1 8M0050098/8M0050099 and 8M0056139 thru 8M0056144
Johnson/Evinrude 1997 - 2019 65-175 HP 64-804378A 1 32-8M0053485
Johnson/Evinrude 1991 - 2019 200-225 HP 64-804378A 1 New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (18 ft)
Johnson/Evinrude 1991 - 2019 250-300 HP 64-804378A 1 Used with 8M0054993/8M0056619 Basic Cylinders as well as the
Johnson/Evinrude 1996 - 2019 90-225 HP Ficht 64-804378A 1 8M0050097/8M0054145 Heavy Duty systems, Also match to helms
Johnson/Evinrude 1998 - 2019 65-70 HP 4-Stroke 64-804378A 1 8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053486
Mercury/Mariner 1984 - 1994 2.4/2,5 EFI 64-804378A 1
New high strength 1500 PSI hose with compression type fittings. Fittings are made
Mercury/Mariner 1989 - 2019 75-300 HP 64-804378A 1 of brass with a nickel plating for extra corrision resistance. (20 ft)
Mercury/Mariner 1998 - 2019 30-60 HP 64-804378A 1 Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
Mercury 2002 - 2019 225 EFI 64-889457A01 8M0050098/8M0050099 and 8M0056139 thru 8M0056144
FourStroke
32-8M0053487
Nissan/Tohatsu 1990 - 2019 90-140 HP 64-804378A 1
New high strength 1500 PSI hose with compression type fittings. Fittings are made
Suzuki 1986 - 2019 100 HP 64-804378A 1 of brass with a nickel plating for extra corrision resistance. (22 ft)
Suzuki 1986 - 2019 115-140 HP 64-804378A 1 Used with 8M0054993/8M0056619 Basic Cylinders as well as the
8M0050097/8M0054145 Heavy Duty systems, Also match to helms
Suzuki 1986 - 2019 150-225 HP 64-804378A 1 8M0050098/8M0050099 and 8M0056139 thru 8M0056144
Suzuki 1998 - 2019 65-70 HP 4-Stroke 64-804378A 1 32-8M0053488
U S Marine/Force 1996 - 2019 90-120 HP 64-804378A 1 New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (24 ft)
Yamaha 1997 - 2019 100-225 HP 64-804378A 1
Used with 8M0054993/8M0056619 Basic Cylinders as well as the
Yamaha 1987 - 2019 225HP 64-804378A 1 8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144
Yamaha 1990 - 2019 250 HP 64-804378A 1
32-8M0053489
Yamaha 1998 - 2019 40-50-60 HP 64-804378A 1
New high strength 1500 PSI hose with compression type fittings. Fittings are made
Yamaha 1998 - 2019 70and 90 HP 64-804378A 1 of brass with a nickel plating for extra corrision resistance. (26 ft)
Yamaha 1994 - 2019 80,100 HP 4- 64-804378A 1 Used with 8M0054993/8M0056619 Basic Cylinders as well as the
Stroke 8M0050097/8M0054145 Heavy Duty systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144
32-8M0053474
New high strength 1500 PSI hose with compression type fittings. Fittings are made
of brass with a nickel plating for extra corrision resistance. (2 ft)
Used with 8M0054993/8M0056619 "Basic" Cylindersas well as the
8M0050097/8M0054145 "Heavy Duty" systems, Also match to helms
8M0050098/8M0050099 and 8M0056139 thru 8M0056144 STEERING

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 669
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
