STEERING

CYLINDER SEAL KIT TWIN ENGINE ADAPTER PLATE

64-826532A 1 64-826511A 2
Replacement front seal for kit for SeaStar front mount cylinders (HC5340/HC5342/ Replacement adapter plate only. Used to connect twin engines utilizing single or
HC5365). Includes 2 seal glands, pin wrench and guide tool. twin front mount outboard cylinder(s) p/n 64‑826491A 1(HC5342).
Fits Mercury/Mariner V‑6 135‑200 HP (1989), 75‑250 HP (1990), 75‑275 HP (1991
BOTTLE FILLER KIT and newer) and Hi‑Perf 2.4/2.5L EFI (1995 and newer).
SEASTAR TIE BAR KIT CHART

Tie Bar Kits
For use with old style front mount outboard cylinder 64‑826491A 1
Brand Year Range Model Tie Bar Kit - Plate
Only
Johnson/Evinrude 2019 90-300 HP N.L.A.
Johnson/Evinrude 2019 300 HP N.L.A.
64-826525A 1 Johnson/Evinrude 2019 65-155 HP N.L.A.
For filling and bleeding of the hydraulic system. Johnson/Evinrude 2019 100-155 HP N.L.A.
Johnson/Evinrude 2019 90-225 HP 64-826512A 2
TELEFLEX NFB SEASTAR TIE BAR KITS Johnson/Evinrude 2019 150-175 HP 64-826512A 2
Johnson/Evinrude 2019 80-105 HP 64-826512A 2
TIE BAR KIT
Mercury/Mariner 2019 90-115 HP 64-826512A 2
Mercury/Mariner 2019 115-220 HP 64-826512A 2
Mercury/Marine 2019 135-250 HP 64-826507A 2
Mercury/Mariner 2019 100-115 HP 64-826512A 2
Mercury/Marine 2019 75-250 HP 64-826507A 2
Mercury/Marine 2019 75-250 HP 64-826507A 2
Mercury/Marine 2019 2.4/2,5 EFI(Perf) 64-826507A 2
Suzuki 2019 150-225 HP N.L.A.
Suzuki 2019 100HP N.L.A.
64-826507A 2
Includes the adapter plates, tie bar and hardware required to connect twin engines RIDEGUIDE ATTACHING KITS
utilizing single or twin front mount outboard cylinder(s) p/n 64‑826491A 1(HC5342).
Fits Mercury/Mariner V‑6 135‑200 HP (1989), 75‑250 HP (1990), 75‑275 HP (1991 Through tilt tube type. When converting tiller handle steering to remote
and newer) and Hi‑Perf 2.4/2.5L EFI (1995 and newer). steering, the existing co‑pilot friction control should be disabled or
removed.
TIE BAR KIT
STEERING LINK ROD KIT

64-826512A 2
Includes the adapter plates, tie bar and hardware required to connect twin engines STEERING
utilizing single or twin front mount outboard cylinder(s) p/n 64‑826491A 1(HC5342). 11606A 1
Fits Mercury/Mariner 90‑115 HP (1984), 115‑220 (1985‑1988), 100‑115 (1989). Starboard cable entry.
Also fits Johnson/Evinrude 80‑225 HP (1991 and newer) Fits Mercury/Mariner 6/8/9.9/15 hp. (2 cyl.) 2 cycle outboards (USA 0A197112 and
Newer, BEL 9461526 and Newer), 8 hp. 4‑Stroke outboards (232 cc) and 9.9 hp.
4‑Stroke outboards (0H000058‑0H016909).
Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 671
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
