HISTORICAL PROPELLER CHARTS

Pre 2008 3 blade Front/Rear Mercury MerCruiser Bravo Three
3 blade front 3 blade rear propellers
For listing of New style 4 blade front 3 blade rear propellers Bravo Three in Mercury Propeller Application Charts section of guide
Mixing of old style and new style props is not recommended for best performance

All Engines
Bravo Three Propeller Hardware (not included with propellers):
Forward Thrust Washer 805101T
Aft Thrust Washer 805100
Forward Prop Nut 859131
Aft Prop Nut 862907
Bravo Three Inner Prop Nut Wrench 805457T 1

Pitch Material Finish Blades (Front & Rear) LH Rotation Front Prop RH Rotation Rear Prop Model
30 Cup SS Matte 3 & 3 Bravo Three
30 SS Matte 3 & 3 48-831867A60 48-831868A60 Bravo Three
28 Cup SS Matte 3 & 3 Bravo Three
28 SS Matte 3 & 3 Bravo Three
26 Cup SS Matte 3 & 3 Bravo Three
26 SS Matte 3 & 3 Bravo Three
24 Cup SS Matte 3 & 3 Bravo Three
24 SS Matte 3& 3 Bravo Three
22 Cup SS Matte 3 & 3 Bravo Three
22 SS Matte 3 & 3 Bravo Three
20 Cup SS Matte 3 & 3 Bravo Three
20 SS Matte 3 & 3 Bravo Three

MerCruiser 215E/215H/All II‑TR & TR
NLA = 48‑57270A1, 48‑57271A1, 48‑54733A1, 48‑54733A4, 48‑57268A1, 48‑57269A1, 48‑54731A1, 48‑54731A4, 48‑57266A1, 48‑57267A1,
48‑54719A1, 48‑54720A1, 48‑54717A1, 48‑54718A1
Thrust Washer 55074T Tab Washer 14‑34817 Washer 12‑55073 (NLA) Nu

Part No. Diameter Pitch Material Blades Rotation Status or Supersession
54726A 4 18 23C AL 3 LH 48- 18619A40
57264A 1 19-1/4 23 AL 3 RH 48- 18618A40
57265A 1 19-1/4 23 AL 3 LH 48- 18619A40
77902A 1 19-1/4 23 AL 3 RH 48- 18618A40
77902A10 19-1/4 23 AL 3 RH 48- 18618A40
48- 18618A40 16-1/2 23C AL 3 RH AVAIL. HISTORICAL PROPELLER CHARTS
77903A 1 19-1/4 23 AL 3 LH 48- 18619A40
77903A10 19-1/4 23 AL 3 LH 48- 18619A40
48- 18618A40 16-1/2 23C AL 3 LH AVAIL.
54727A 1 18-1/2 21 AL 3 LH 48- 18617A40
54727A 4 18-1/2 21C AL 3 LH 48- 18617A40
57262A 1 19-1/2 21 AL 3 RH 48- 18616A40
57263A 1 19-1/2 21 AL 3 LH 48- 18617A40
69262A 1 19-1/2 21 AL 3 RH 48- 18616A40
77900A 1 19-1/2 21 AL 3 RH 48- 18616A40
77900A10 19-1/2 21 AL 3 RH 48- 18616A40
48- 18616A40 16-3/4 21C AL 3 RH AVAIL.
77901A 1 19-1/2 21 AL 3 LH 48- 18617A40
77901A10 19-1/2 21 AL 3 LH 48- 18617A40
48- 18617A40 17-3/4 21C AL 3 LH AVAIL.
54725A 1 19 19 AL 3 LH 48- 18615A40
54726A 1 19 19 AL 3 RH 48- 18614A40
63305A 1 19-3/4 19 AL 3 LH 48- 18615A40
63306A 1 19-3/4 19 AL 3 RH 48- 18614A40
69260A 1 19-3/4 19 AL 3 RH 48- 18614A40

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 901
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
