Engine adjusting tools Injector puller
Universal assortment for engine adjustment For the removal of fixed Common Rail injectors without disassembly
Universally applicable and adjustable, e.g. during toothed belt change of the cylinder head, e.g. on MERCEDES-BENZ CD engines 611, 612,
For toothed belt change and other engine servicing work. 613, etc.
For gasoline and diesel engines with one or two upper cam shafts. Specially adapted to tight spaces due to the cylinder head cover.
For locking the injection pump of the cam shaft into place.
The use of this locking tool guarantees that the cam shaft wheels/
injection pump wheels assume the correct position in relation to the
crankshaft during a toothed belt change or engine servicing.
Easily understandable operating instructions.
Optionally available individual parts
Clear accommodation in high-quality plastic case with soft foam insert.
5-part assortment.
Content:
Locking mechanism, extension rail, base device, locking pin (short), and
locking pin (long)

Contents Art. No. P. Qty.

2-part set:

1952 000 529 1
Door hinge pin remover
1952 000 530 1
Injector claw
M 16 x 1.5
1952 000 531 1
Outer adapter
with inner thread. In combination with the door hinge pin remover
1952 000 530.
The outer adapter is used when the injector claw cannot be used
Contents Art. No. P. Qty. due to design or insufficient space.
Note: after removing the injector and outer adapter, replace
1952 000 517 1 the injector.
Locking mechanism 1952 000 532 1
1952 000 518 1
Extension rail Two-component soft foam insert
1952 000 519 1 Safety Insert System – all tools are embedded in a shake-
Base device proof manner.
A missing tool is noticed immediately.
1952 000 520 1
For all HAZET i tool trolleys with drawers.
Locking pin (short)
For i tool trolleys 173, 179, and 180, we also recommend
1952 000 521 1
plastic insert 173-36/5 or soft foam inserts 163-522x40 or 163-522x50.
Locking pin (long)
1952 000 522 1

Contents Art. No. P. Qty.

5-part
engine adjustment tools (1/3)
Universal assortment for professional engine servicing
(see 1952 000 517)
Contents:
Locking mechanism, extension rail, base device, locking pin
(short and long) 1952 000 127 1
