Universal adapter Professional endoscope
“Torsion 360” – Reduced torsional moment enables 360°
rotation around the longitudinal axis without force.
Outer diameter of 4.2 mm, e.g. for the diagnosis of modern diesel
vehicles (visual inspection via the glow plug shaft)
17,000 glass fibers provide for an optimum resolution.
Optimization of the focal distance for a minimum observation of the
distance (from 5 mm)
By turning the fiber optic cable and the side view adapter, a round-
about field of vision is guaranteed.
Variable focusing of the ocular for optimal images (blue adjusting ring)
On/off switch with variable light regulation
Large overview field due to large opening angle (40°)
Contents Art. No. P. Qty. Minimum bending radius (30 mm) for hard-to-reach places,
e.g. bending in lines and hoses
Specially coated achromatic lens system for pictures without color
For cooler openings of dia. 20 - 41 mm, fringing
3-stage coarse adjustment plus fine adjustment Brightness up to 15,000 Lux at a distance of 16 mm
1952 000 548 1 Water-tight endoscope probe. Brief use also possible in oil
and gasoline.
Especially for Japanese vehicles, dia. of 18 - 24 mm Range of application: –20 to +55°C
Clamp attachment Fast adaptation of the battery handle to the base device
1952 000 549 1 due to patented bayonet connection
Eyepiece cup for users who wear glasses.
Useful length: 720 mm, flexible
Borescope Optional screw-on side view adapter 90° 4811-4 or 110° 4811-5
Battery handle with three commercial batteries (LR 14)
With 2.5 V XHL xenon halogen lamp and battery-operated (up to 10 hours working time)
handle, incl. batteries
For openings from dia. of 1 mm, enables view to a depth of 250 mm Scope of delivery:
Optimally suited for the visual inspection of hard-to-reach areas or Endoscope 1952 000 067 consisting of:
- Endoscope
areas that cannot be seen, e.g. lock cylinders, cracks, boreholes, - Battery handle with three batteries (LR 14 )
nozzles, etc.
Up to 10x enlargement. - Eyepiece cup
17 upstream lenses permit the checking of objects at a distance of Practical plastic case with soft foam insert for safe accommodation
and additional empty compartments, e.g. for small parts
5-250 mm.
Working without goggles possible. Application:
With integrated lit distance display For the assessment and creation of damage diagnoses around and in
With bag clip. hidden areas, like:
Low weight of only 100 g Cars, utility vehicles, motorcycles, boats:
Engine areas like cylinder walls, pistons, valves, oil pumps, oil pans,
transmissions, etc.
Art. No. 1952 000 550 P. Qty. 1
Diagnosing of leaks in engines and cooling systems, visual inspection
of the catalytic converter, body areas, chassis, tiebars, shafts, axle
wear, such as bearing rings, ball bearing, running traces on the axle
body, drive shafts, etc.
Industry:
CNC machines, planetary gears, bearings and liners, guides and
grooves, etc.
Quality testing in the surface area, welding seams, soldered connec-
tions, riveted connections, all types of screw connections, and all types
of boreholes and threads
Aeronautics:
Sporting planes with engines, helicopters, chassis, cylinder engine
areas; valve/valve block, piston/piston ring
Windshield wiper adjusting device Construction
For adjusting the windshield wiper angle adjustment via the wiper arm Refurbishing of old buildings, hollow spaces, cable ducts, etc.
in relation to the windshield.
– Adjust according to manufacturer’s data - Art. No. 1952 000 067 P. Qty. 1
Not for Aerotwin windshield wipers!

MWF - 06/08 - 11560 - © • K Art. No. P. Qty.
120 x 65 x 60
1952 000 554 1

60
