PlAn reGion tool • Project BrowSer 947

Plan Region tool, 53 positioning. See also coordinate systems
Plan View command, 38–39 Auto - By Shared Coordinates, 222, 234, 239
plan views, 37, 38, 43, 52, 88, 203, 913 Auto - Origin To Origin, 234, 238, 245, 247
Plan Views tool, 52 shared, linked models, 202–203
Plan01.dwg, c07, 238 postpone option, Coordination Review dialog box, 223
Plane tool, 279 PowerPoint presentation rendering, 471, 878
planning, for LiDAR scan, 852–854, 865, 888 predefined line weight templates, 231
plans. See area plans; floor plans predefined settings, for inserted CAD data, 230
poché presenting designs, 823–846
quick-cut, 909, 909 Bottom Line, 845–846, 887–888
section box, 432–433, 433 color fill legends, 823–834
topographic surface, 99, 100 Bottom Line, 845, 887
Point Cloud Level of Detail, 853 customizing, 828, 828–830, 829, 830
point clouds, 847–865. See also LiDAR modify settings, 830–831, 831
accuracy, 850 numerical ranges for color schemes, 832–833,
axonometric section of industrial building, 850, 833
850 program verification, 834
Bottom Line, 865, 888 rooms, 824–827, 825, 826, 827
defined, 854 exploded axonometric views, 839–845, 840, 841,
getting started, 856–860, 857, 858, 859, 860 842, 843, 844, 845, 846, 887–888
heat map for floor deflection, 852, 852 overview, 823
imagery, 853–854, 854 3D views, 834–837
industrial plant, 851, 851 annotating, 837, 837
introduction, 847 Auto-Section Box tool, 836
large, 859 orienting to other views, 834–836, 835, 836
minutiae management, 863 viewport types, 838, 838–839, 839, 846, 887
modeling with, 860–864, 861, 862, 863, 864 Preview Window, Edit Assembly dialog box,
optimize performance, 888 478, 479
Point Cloud Level of Detail, 853 primary design option, accepting, 399–401
raw formats, 854–855 Print Setup dialog box, 49, 109
size, 855 Pr-Mullion-Head > Kawneer-1600-Sys1-
tips, 864 Head.rfa, 709
Point Element tool, 525 Pr-Mullion-Sill > Kawneer-1600-Sys1-Sill
point elements, 317–320, 318, 319 .rfa, 709
points profiles
driving points, 329 Massing-2-Start.rvt, 294, 294
hosted points, 329, 334, 525, 526, 526, 528, 529 railings, 628
Measure From value, 331 Select Profile option, 311, 549, 611, 612
reference points walls, 497–499, 498, 499, 537, 879
adaptive component, 327, 328, 333 Project Base Point, 205–208, 206
complex mass family, 318 Project Browser
defined, 328 Browser Organization dialog box, 133–135
described, 586, 587 Browser Organization Properties dialog box,
driving points, 329 133, 133, 134
free points, 329 Browser Organization tool, 27, 27
Project Base Point, 205–208, 206 Certification Objective, 26
types, 328–329 customizing, 871
points file, toposurface creation, 95 described, 25–27, 26
Points.csv, c03, 95 tabbed or stacked palette, 27, 28
portability settings, 209 undocking, 27

bindex.indd 947 05-05-2014 16:28:40
