Topologies and IDS • Chapter 7 449

Deploying a NAT Solution
Damage & Defense… cable/DSL “routers,” because they allow you to connect multiple com-
NAT is relatively easy to implement, and there are several ways to do so.
Many broadband hardware devices (cable and DSL modems) are called

puters. However, they are actually combination modem/NAT devices
rather than routers, because they require only one external (public) IP
address. You can also buy NAT devices that attach your basic cable or DSL
modem to the internal network. Alternatively, the computer that is
directly connected to a broadband modem can use NAT software to act
as the NAT device itself. This can be an add-on software program or the
NAT software that is built into some OSes. For example, Windows XP and
Vista include a fully configurable NAT as part of its Routing and Remote
Access services. Even older versions of Microsoft products such as
Windows 98SE, Me, and 2000 Professional include a “lite” version of NAT
called Internet Connection Sharing (ICS).
For a quick, illustrated explanation of how NAT works with a broad-
band connection, see the HomeNetHelp article at www.homenethelp.
com/web/explain/about-NAT.asp.

When NAT is used to hide internal IP addresses (see Figure 7.11), it is some-
times called a NAT firewall; however, do not let the word firewall give you a false
sense of security. NAT by itself solves only one piece of the security perimeter
puzzle.A true firewall does much more than link private IP addresses to public
ones, and vice versa.

Figure 7.11 NAT Hides the Internal Addresses

The NAT router has a routing table that keeps track of all connection
requests that originate from the internal network. The NAT router
modifies all outgoing packets, by replacing the internal client’s
IP address with its own IP address, and then forwards them to
their destination (or next hop). Returning packets are then 192.168.5.112
routed back to the correct internal client by using the routing table.
192.168.5.157
Requests that originate from the Internet can be routed to the
correct internal client as long as a static mapping has been Client
created in the NAT router’s table.
Client

Internet
NAT Router
Client
LAN: 192.168.5.1 192.168.5.149
WAN: 42.42.42.42
