11 Bluetooth Adapter
®
632

®
®
Bluetooth Adapter in Connection with 750 Series Bluetooth Adapter in Connection with 857 Series
®
®
The Bluetooth Adapter wirelessly connects a notebook computer with The Bluetooth Adapter wirelessly connects a notebook computer with
®
®
Bluetooth functionality to the service interface of the buscoupler/controller. Bluetooth functionality to the service interface of a configurable 857 Series
®
It also provides an active connection to a programmable fieldbus controller. JUMPFLEX Module.
®
®
As a cable substitute, the Bluetooth Adapter allows communication between As a cable substitute, the Bluetooth Adapter allows communication between
®
two fieldbus controllers, as well as between fieldbus couplers/controllers via JUMPFLEX Modules and WAGO software tool (WAGOframe) or
WAGO software tools (e.g., WAGO-I/O-CHECK, WAGO-I/O-PRO). configuration APP for Android-based end devices.
Configurable coexistence properties ensure trouble-free operation in the
presence of other radio systems. If required, adapter configuration may be performed via AT commands.
The adapter is supplied via both service interface and power supply of
®
coupler/controller or JUMPFLEX module.
Description Item No. Pack. Technical Data
Unit
®
Bluetooth Adapter 750-921 1 Data transfer rate 9600 ... 115000 bps
Frequency range 2.4 ... 2.4835 GHz (ISM band)
Type of communication Point-to-point connection
Profiles supported Serial Port Profile (SPP)
Version 2.1
Radio class Class 2
RF output power max. +4 dBm (class 2)
RF input sensitivity typ. -82 dBm
Antenna integrated
Ports 4-pole service connectors
Configuration AT commands (e.g. via Hyper Terminal)
Function Master or Slave
LED Operating status
Operating temperature -20 °C ... +60 °C
Current consumption (internal) 60 mA
Security authentification PIN code or configurable access list
Security encryption 128-bit encryption
Dimensions (mm) W x H x L 15 x 50 x 19
Weight 7 g
Coexistence Frequency Hopping Spread Spectrum
(FHSS),
Adaptive Frequency Hopping (AFH),
Approvals Adaptive transmission power with
configurable upper limit,
Conformity marking 1 configurable channel blacklist,
®
Bluetooth approval supports coexistence optimized inquiry
(transmission time ≤ 0.1 s;
transmission cycle ≥ 2.9 s)
