11 Operating tool

686

Operating tool Operating tool Operating tool
with partially insulated shaft with partially insulated shaft with partially insulated shaft, short
for optimum handling of terminal blocks – Set – for optimum handling of terminal blocks

Item No. Pack. Unit Item No. Pack. Unit Item No. Pack. Unit
Operating tool, with partially insulated shaft, Operating tool, with partially insulated shaft, Operating tool, type 1, short, straight blade
type 1, blade (2.5 x 0.4) mm – Set – (2.5 x 0.4) mm, with partially insulated shaft
210-719 1 210-722 1 210-647 1
Operating tool, with partially insulated shaft, Operating tool, type 2, short, straight blade
type 2, blade (3.5 x 0.5) mm (3.5 x 0.5) mm, with partially insulated shaft
210-720 1 210-657 1
Operating tool, with partially insulated shaft, Operating tool, type 1, short, angled blade
type 3, blade (5.5 x 0.8) mm (2.5 x 0.4) mm, with partially insulated shaft
210-721 1 210-648 1
Operating tool, type 2, short, angled blade
(3.5 x 0.5) mm, with partially insulated shaft
210-658 1

Wiring example showing
WAGO-I/O-SYSTEM 750
The operating tool are particularly appropriate for the
operation of front-entry terminal blocks and connectors.
(The picture shows the WAGO-I/O-SYSTEM 750)
