Gas/Liquid Separation Fabricated Construction

Gas/Liquid Separators
Type 30L Series

Horizontal or Vertical

Fabricated Construction

• 10 Models for
Application Flexibility

• Low Profile Type 31-L

• Horizontal or Vertical Flow
High Efficiency – helps direct the clean, dry
• Flanged Connections No Maintenance flow to the outlet of the
separator.
The Eaton Type 30L Gas/Liquid
• Fabricated Carbon Steel or Stainless Steel Separator automatically There are 10 different models
available to match the needs
removes 99% of all liquid
Construction and solid entrainment particles of just about any application
10 microns in size or larger. no matter what the flow
And it does so with no moving direction or piping system
parts to break or wear out. orientation.
FEATURES Series 30L Gas/Liquid
• Compact Design Separators perform to Type 30L Series with In-line
• No Required Maintenance specification year in and year Piping Connections
out with no maintenance.
• Removes 99% of Liquid and Solid Entrainment The Type 31-L Separator is an
Particles Larger Than 10 Microns Operation in-line separator that can be
• Gas, Steam, or Air Applications installed horizontally or
Moisture-laden gas enters the vertically for downflow
inlet of the separator where it applications. Models installed
OPTIONS is deflected through a unique horizontally can be ordered
Cenpellar™ into a centrifugal with sump and water gauge
• Oversized Inlet Connections
motion. The entrained solids mountings. Horizontally and
• Reduced Size Inlet and Outlet Connections and moisture droplets are vertically installed models can
• Different Flow Patterns separated out by a reduction be furnished with reduced size
in velocity of the flow. inlet and outlet flanges to
• Integral Sump Separated liquids and solids accommodate higher flow
• ASME Code Stamp fall out of the gas stream rates in smaller pipelines with
• Support Legs below the exclusive Eaton an acceptable pressure drop.
Vortex Containment Plate In all, five different
(VCP) where they cannot be configurations are offered
re-entrained. The VCP to meet exact application
eliminates the need for the requirements. The Type 32-L
Type 32-L
expensive, delicate baffles is an in-line vertical upflow
used in other separators, and separator.

Type 31-LS
