Suction Cups for Handling Sheet Metal
Bell-Shaped Suction Cups SAOG (Oval)
PA01019111_inh_EN_KORR_175.pdf container Suitable for Industry Specific Applications Schmalz - The Company PA01019111_inh_EN_KORR_175.pdf
Suction area (LxW) from 60 x 20 mm to 95 x 40 mm

container
Applications
• Oval bell-shaped suction cup for handling of long, oiled Vacuum Knowledge
workpieces with extremely small curved radii
• Very dynamic handling of metal sheets (short cycle times)
• Inner support for deformation-free handling of thin steel sheets Suction Cups
and aluminum sheets or deep-drawing Vacuum
• Usage in feeder systems for press lines in the automobile industry
• Slot lot on the bottom prevents oily sheets from slipping; permits
precise positioning in stamping presses etc.
Special Grippers

Vacuum Grip- ping Systems
Bell-shaped suction cups SAOG (oval)
container
Design

• Oval, bell-shaped suction cup with single sealing lip, special slot
and inner support Mounting Elements
• Suction cups made of NBR material, hardness 45 Shore

Vacuum Generators

Valve Technology

System design bell-shaped suction cups SAOG (oval)
Switches and
container
Our Highlights... Your Benefits... Monitoring
• Oval, bell-shape >Optimum adaptation to
narrow, very curved
workpieces Connections
• Material NBR, material >Adaptation to workpieces Filters and
hardness 45 Shore with small curved radii
• Wide range of connection >Mounting on all common load
elements cross-beams and feeder
systems possible Services

Contact
Bell-shaped suction cups SAOG being used for handling very curved sheet metal parts

Index of Products

container
www.schmalz.com/saog
