Suction Cups for Packaging
Bellows Suction Cups FGA PVC (1.5 Folds)
PA01019111_inh_EN.pdf Suction area (Ø) from 13 mm to 22 mm PA01019111_inh_EN.pdf

container
Designation Code Bellows Suction Cups FGA PVC (1.5 Folds)
Schmalz - The Company container Abbreviated designation Suction area Ø Material and Type connection element

Example FGA 13 PVC-50 N016: in mm Shore hardness N016
PVC-50
FGA
13
Vacuum Knowledge FGA 13 PVC-50 N016
19
N056
22
Vacuum Suction Cups container Ordering Data Bellows Suction Cups FGA PVC (1.5 Folds)

Suction cup FGA PVC (elastomer part) is supplied as an individual part. In order to receive a complete suction cup (elastomer part +
container
connection nipple), the following ordering steps are required:
• Suction cup of type FGA PVC (step 1) – elastomer part, available in various diameters
Special Grippers • Connection nipple of type SA-NIP (step 2) – available with various threads

container Step 1: Bellows Suction Cups FGA PVC (1.5 Folds) (Single Component)
Vacuum Grip- ping Systems container Type Part Number

FGA 13 PVC-50 N016 10.01.06.01549
FGA 19 PVC-50 N056 10.01.06.01975
Mounting Elements FGA 22 PVC-50 N016 10.01.06.01947
*Additional material specifications at beginning of the section "Vacuum Suction Cups"

container
Step 2: Connection Nipples Bellows Suction Cups FGA PVC (1.5 Folds)
Vacuum Generators container Type M5-AG G1/8-AG G1/8-IG

FGA 13 PVC
10.01.06.03571
10.01.06.03080
10.01.06.03572
FGA 19 PVC 10.01.06.00123 10.01.06.05735 10.01.06.05731
10.01.06.05731
10.01.06.05735
10.01.06.00123
FGA 22 PVC
Valve Technology container
Technical Data Bellows Suction Cups FGA PVC (1.5 Folds)
Switches and Monitoring container Type Suction force Pull-off force Volume Min. curve radius Recommended inter-
nal hose diameter
[N]
[cm³]
[mm]
[N]*
FGA 13 PVC-50 N016 1.7 10 6 0.6 (convex) d [mm]** 4 4
10
20
2.0
5.9
FGA 19 PVC-50 N056
Filters and Connections FGA 22 PVC-50 N016 5.3 16 2.3 20 4
*The specified suction forces are theoretical values at a vacuum of -0.6 bar and with a smooth, dry workpiece surface - they do not include a safety factor
**The recommended hose diameter refers to a hose length of approx. 2 m
Services

Contact

Index of Products

242 www.schmalz.com/fga-pvc
