Suction Cups for Handling Glass
Bellows Suction Cups SAB HT1 (1.5 Folds)
PA01019111_inh_EN.pdf Suction area (Ø) from 22 mm to 125 mm PA01019111_inh_EN.pdf

container
Schmalz - The Company Suitable for Industry Specific Applications

container
Applications

Vacuum Knowledge • Round bellows suction cup with 1.5 folds for dynamic handling of
glass workpieces
• Handling of flat glass and formed glass pieces

Vacuum Suction Cups • Use in automated production lines for automotive windscreens or
side windows, even after the bending process at temperatures up
to 170° C
• Exact positioning in production processes without displacement

Special Grippers • High lateral forces in use with separation powder on flat glass or
on damp surfaces

Vacuum Grip- ping Systems Bellows suction cups SAB HT1 (1,5 folds) Design

container

• Robust and hard-wearing bellows suction cup made of HT1 with
1.5 folds, with special slot and inner support
Mounting Elements • Suction cup is vulcanized to the connection nipple (for very high

strength)
• Special structure of the suction surface with high performance
Vacuum Generators profile

Valve Technology System design bellows suction cup SAB HT1 (1.5 folds)

Switches and Monitoring container Our Highlights... Your Benefits...

>Minimal chemical influence
• Non-marking material HT1
on the workpiece surface
Filters and Connections • High temperature resistance >Handling of hot workpieces
without modification of the
material properties
• Large, structured inner >Capable of handling high
support lateral forces, especially in
Services use with separating powder
and wet workpieces
• 1.5 folds >Optimum adaptation and
sealing to curved workpieces,
very good damping
Contact Bellows suction cups SAB HT1 being used for handling glass • Very stiff top fold >Very good resistance to

lateral forces and lateral
acceleration
Index of Products

264 www.schmalz.com/sab-ht1
