Vacuum Area Gripping Systems SBX
Types
PA01019111_inh_EN.pdf PA01019111_inh_EN.pdf

Schmalz - The Company

Vacuum Knowledge

Vacuum Suction Cups

SBX 200 with Vacuum Generation SBX 200 for External Vacuum Generation
• Multi-stage ejector SEM 150 with dust filter • Connection piece for external vacuum generator Grippers
• Vacuum generation directly at the gripper ensures fast • Use of electrical vacuum generators (blower or pump) to Special
evacuation achieve high flow rates and vacuum up to -0.8 bar
• Easy mounting and installation without the need to connect • Low operating costs due to electrical vacuum generation
additional hoses Vacuum Grip- ping Systems
• Ejector and dust filter can be optionally integrated into the
base section

Mounting Elements
SBX 400 for External Vacuum Generation
• Double gripper design for maximum holding forces
• Increased hit rate due to offset suction cell grid, thus
parti cu larly suited for thin workpieces
• Use of electrical vacuum generators (blower or pump) to Vacuum Generators
achieve high flow rates and vacuums up to -0.8 bar

Valve Technology

Switches and Monitoring

Filters and Connections

Services

Contact

Index of Products

www.schmalz.com/sbx 391
