Vacuum End Effectors VEE
Configuring Rather than Designing
PA01019111_inh_EN.pdf PA01019111_inh_EN.pdf

Schmalz - The Company Suitability for industry-specific applications

Application
Vacuum Knowledge • Fast and cost-effective design of vacuum end effectors for high-
speed packaging processes

robots
Vacuum Suction Cups • Pick-and-place applications with Delta, SCARA and articulated
• Fully automated filling of cardboard boxes and case packers
• Mainly used in primary and secondary packaging processes

Special Grippers • Transporting products into top-loading machines, and card-
board box and tray erectors
• Use in flexible packaging machines with frequent format
Vacuum Grip- ping Systems The vacuum end effector with vacuum module and bellows suction cups SPB4f handling
changes
flexible packages

Mounting Elements

Vacuum Generators

Valve Technology

Switches and Monitoring Vacuum end effector with flat suction cups SPF handling boxes of tea The vacuum end effector with bellows suction cups SPB4f handling pouches with
strong wrinkling and low filling degree

Our highlights … Your benefits …
Filters and Connections • Perfectly coordinated individual components >Flexible gripper configurations with variable suction cup number

and positioning
• Online configurator with generation of CAD data >Minimizes configuration and setup times by more than 80 %
and parts list
Services • Light weight (ready-to-connect end effectors starting at 150 g) >Designed for high-speed applications with accelerations of up to
10 g (100 m/s²)
• FDA and BfR-compliant (German Federal Institute for Risk >Excellent resistance to alkaline cleaning agents
Assessment) high performance thermoplastic
Contact • With optional integrated vacuum generation using the Schmalz >Fast, energy-efficient vacuum generation right at the gripper
eco nozzle technology
• Assembly service >Delivery of entire assembled, ready-to-connect vacuum end
effectors
