Pressure-Reduction Valves DM
PA01019111_inh_EN.pdf Working range from 0.5 bar to 10.0 bar PA01019111_inh_EN.pdf

container
Schmalz - The Company container Design Data Pressure-Reduction Valves DM

Vacuum Knowledge

Vacuum Suction Cups

Special Grippers DM 0.5...10.0 G1/2 BEF-WIN 16x78x64 2

Vacuum Grip- ping Systems container Type Dimensions in mm B2 d d1 G1 H H2 H3 L s X1 X2 Y1
B1
B
DM 0.5...10 G1/2-IG
64.0
BEF-WIN 16x78x64 2 64.0 96.0 - 32.0 - 4.2 - 6.5 - G1/2"-F - 135.5 43.5 8.0 - 64.0 2.0 - 39.5 - 52.0 - 27.0 -
12.3
78.0
16.0
Mounting Elements container Functional Circuit Diagram Pressure-Reduction Valves DM
container
Vacuum Generators

Valve Technology

Switches and Monitoring

Filters and Connections Circuit diagram DM (1 = pressure; 2 = vacuum)
