Hoses and Connectors
Screw in Push Fittings
PA01019111_inh_EN.pdf Hose outer diameter from 4 mm to 14 mm PA01019111_inh_EN.pdf

container
Schmalz - The Company Suitable for Industry Specific Applications

container
Applications
Vacuum Knowledge • Screw in push fittings for quick connection of smooth hoses
without the need for tools
• For use as a connecting element in vacuum systems
Vacuum Suction Cups • Suitable for hoses with external tolerances in accordance with
CETOP RP 54 P

Special Grippers

Vacuum Grip- ping Systems Screw in push fittings Our Highlights... Your Benefits...

container
Design

• Screw in push fitting, clamping clip and unlocking element made • Screw in push fittings with >Quick and safe connection
Mounting Elements of nickel-plated brass integrated clamping clip and disconnection of all
smooth hoses without the
• Hose-connection sealed with an NBR gasket
need for tools
• Whitworth pipe thread • Hoses clamped on the outside >No pinching of the hose: full
Vacuum Generators cross-section remains open

• Absolutely vacuum-tight, >Specially designed for vacuum
shaped for optimum flow applications
Valve Technology • Body and clamping clip made >Suitable for very rough use;
of nickel-plated brass long lifetime; re-usable
Switches and Monitoring • Various versions available >The right connection for every
application

container
Technical Data Screw in Push Fittings
Filters and Connections container Type Pressure range (operating pres- Operating temperature [°C] Material

sure) [bar]
Screw in Push Fittings -0.95 ... 15.00 -20 ... 80 Brass

Services

Contact

Index of Products

720 www.schmalz.com/stv
