Electronic Pressure Switch

display
turns thru
270°

housing
turns thru
340°

hex. SW27

Elastomer profile gasket
DIN 3869

male electr. conn. M12x1
4 pole/5 pole

Pin Pin EDS 33X6-1 & EDS 33X6-2 & EDS 33X6-3 &
Connections EDS 34X6-1 EDS 34X6-2 EDS 34X6-3
1 +U B +U B +U B
2 n.c. SP 2 Analog
3 0 V 0 V 0 V
4 SP 1 SP 1 SP 1
M12x1, 4 pole

Pin EDS 33X8-5 & EDS 34X8-5
1 +U B 4 3
5
2 Analog
3 O V 1 2
4 SP1
5 SP2 M12x1, 5 pole

DESINA ® Compliant Can be connected to DESINA ®
NOTES: Pin EDS 33X8-1 EDS 33X8-3
The information in this brochure 1 +U B +U B
relates to the operating 4 5 3
conditions and applications 2 Diagnostics Diagnostics
described.
For applications or operating 3 O V O V 1 2
conditions not described, please 4 SP 1 SP 1
contact the relevant technical
department. Subject to technical 5 n.c. Analog
modifications. M12x1, 5 pole
