PDE2600PNUK
Parker Pneumatic Origa OSP-E Electric Linear Actuators

Options and Accessories

OSP-E..BV, Vertical belt actuator
with integrated ball bearing guide

STANDARD VERSION
OSP-E..BV

Standard actuator head with DRIVE SHAFT ACCESSORIES
clamp shaft or plain shaft and "CLAMP SHAFT AND PLAIN
integrated ball bearing guide with SHAFT" OR "DOUBLE PLAIN MOTOR MOUNTINGS
two carriers. SHAFT" For connection of gearbox or
Choice of side on which gearbox e.g. for parallel operation of two motor direct to drive shaft with
or motor is to be mounted. Z-axes with an intermediate drive clamp shaft, or with a motor
shaft. coupling to drive shaft with plain
shaft.

Drive Shaft with Drive Shaft with
Drive Shaft with Drive Shaft with Clamp Shaft and Double Plain
Clamp Shaft Plain Shaft Plain Shaft Shaft

MAGNETIC SWITCHES SET
Magnetic switches with
connector, mounting rail and
magnets for contactless sensing
of the end positions. Cable
(suitable for cable chain) can
be ordered separately in 5 m,
10 m or 15 m length.

OPTIONS Magnet

TANDEM Magnetic Switch
Additional actuator head and two HOLLOW SHAFT WITH KEYWAY Magnetic Switch
additional carriers for higher For direct connection of gearbox
bending moments. or motor with keyway. Magnet

MULTI-AXIS SYSTEMS
For modular assembly of
actuators up to multi-axis
systems.

Parker Hannifin Corporation
Pneumatic Division - Europe
312
