Parker Pneumatic Origa HMR Rodless Electric Linear Actuators

ORIGA HMR Electromechanical Linear Actuators

We drive the future - with screw, toothed belt.

Profile designs Position sensing
 Basic profile for assembling  Integrated, adjustable
directly to the machine base position switch for end
 Reinforced profile for self- positions and homing
supporting assembly
Mounting systems Impact protection
 Integrated T-slots for attaching  Integrated shock absorbers
from below and from the side for both end positions

Protection classes Distance measurement
 Without cover: IP20  Contact-free, incremental
 With cover: IP54 displacement measuring
system

Guide systems Brake system
 Plain bearing guide  Holding brake can be
 Recirculating ball implemented for horizontal
bearing guide and vertical movements

Lubrication Cable drag chains
 Central lubrication via  Directly attachable drag
externally accessible chains for various cabling
lubricating nippels

Toothed belt drive
The solution for fast path and
position control for medium
loads

Screw drive
The solution for precise path
and position control for heavy
loads
