Connectors and Headers
5
MCS MIDI 100 % Protected Against Mismating 5
305

Pin spacing: 5 and 7.5 mm / Nominal cross section 2.5 mm 2

Pin Spacing Pages
Female Connectors,
Straight and Angled,
®
CAGE CLAMP Termination 5 mm/0.197 in. 308 – 311
7.5 mm/0.295 in. 338 – 340

Female Connectors
for Panel Mounting,
CAGE CLAMP Termination 5 mm/0.197 in. 312 – 313
®
7.5 mm/0.295 in. 342 – 343

Female Connectors with Push-Buttons, 5
®
CAGE CLAMP S Termination 5 mm/0.197 in. 314 – 316
7.5 mm/0.295 in. 344 – 346

Female Connectors, 2-Conductor,
CAGE CLAMP S 5 mm/0.197 in. 318 – 319
®
7.5 mm/0.295 in. 348 – 349

Male Headers with Solder Pins 5 mm/0.197 in. 320 – 322
7.5 mm/0.295 in. 350 – 352

Male Headers with Press-In Pins 5 mm/0.197 in. 320 – 321

Male Connectors,
CAGE CLAMP Termination 5 mm/0.197 in. 324 – 327
®
7.5 mm/0.295 in. 354 – 357

Female Connectors with Solder Pins 5 mm/0.197 in. 328 – 331
7.5 mm/0.295 in. 358 – 361

Male Connectors for Rail-Mounted Terminal Blocks 5 mm/0.197 in. 332 – 333

Female Connectors for Rail-Mounted Terminal Blocks 5 mm/0.197 in. 334 – 336

MCS MIDI Accessories 470 – 480
Direct Marking 362 – 364

Accessories, General — Section 12 554 – 576
Application Examples 481 – 487
