Male Connectors for Front-Entry, Rail-Mounted Terminal Blocks
5 Pin Spacing: 5 mm
332 MCS MIDI
● Pluggable connectors for rail-mounted terminal blocks equipped with
CAGE CLAMP ®
● Male connectors with long contact pins connect to the termination
ports of 280 Series rail-mounted terminal blocks

● Pins can be touched when the connector is unplugged, so power
supply should be performed via terminal block (observe rated
voltage!)

● 100% protected against mismating
● With coding elements

Technical data:

Pin Spacing 5 mm Derating Curve
0.197 in. 721-102/026-000 female connector
Ratings per IEC/EN 60664-1 with 721-162/003-000 male connector
2
Overvoltage category III III II Pin spacing: 5 mm / Conductor size: 2.5 mm “f-st”
Pollution degree 3 2 2 Based on: EN 60512-5-2 / Reduction factor: 0.8
Rated voltage on feed-in via the header 250 V 320 V 630 V Current in A
Rated voltage when power is supplied via rail-mounted terminal block 50 V 50 V 50 V 45
Rated surge voltage 4 kV 4 kV 4 kV 40
Nominal current 16 A 16 A 16 A 35
Approvals per UL/CSA 30
Use group UL 1059 B C D 25
Rated voltage 300 V – 300 V 20
Nominal current UL 15 A – 10 A 15
Nominal current CSA 15 A – 10 A 10
The MCS MIDI connection system is UL 1977 approved and capable of up to 600 V for factory wiring. 5
0 10 20 30 40 50 60 70 80 85
Ambient operating temperature in °C
2-, 4-, 6-, 12-, 20-pole Conductor rated current

Material data: MCS MIDI accessories: Pages:
Material group I
Insulating material Polyamide 6.6 (PA 6.6) Operating tools 471
Flammability rating per UL 94 0V Coding keys 472
Lower/Upper limit temperature -60 °C / +100 °C
Contact material Electrolytic copper (E )
Cu
Contact plating tin-plated
MCS — MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with
DIN EN 61984.
When used as intended, these connectors shall not be connected/disconnected when live or under load. The circuit
design should ensure header pins, which can be touched, are not live when unmated.

Additional approvals and corresponding ratings can be found at www.wago.com. For additional technical information, see Section 13.
