12 Operating Tools

556

Operating Tools Operating Tools Operating Tools

with partially insulated shaft with partially insulated shaft with partially insulated shaft
Type 1, 2 and 3 Type 1, 2 and 3 in set Type 1 and 2, short

Item No. Pack. Unit Item No. Pack. Unit Item No. Pack. Unit
Operating tool, type 1, (2.5 x 0.4) mm blade, Set of operating tools Operating tool, type 1, short, (2.5 x 0.4) mm straight
with partially insulated shaft, suitable for Type 1, (2.5 x 0.4) mm blade blade, with partially insulated shaft, suitable for 218, 233,
218, 233, 234, 235, 250, 253, 730, 733, 734, 735, Type 2, (3.5 x 0.5) mm blade 234, 235, 250, 253, 730, 733, 734, 735, 739, 713,
739, 713, 714, 805 and 2734 Series Type 3, (5.5 x 0.8) mm blade 714, 805, and 2734 Series

210-719 1 210-722 1 210-647 1
Operating tool, type 2, (3.5 x 0.5) mm blade, with Operating tool, type 2, short, (3.5 x 0.5) mm straight
partially insulated shaft, suitable for blade, with partially insulated shaft, suitable for 226, 231,
226, 231, 232, 235, 236, 237, 246, 250, 254, 255, 232, 235, 236, 237, 246, 250, 254, 255, 256, 257,
256, 257, 721, 722, 723, 731, 732, 733, 735, 736, 721, 722, 723, 731, 732, 733, 735, 736, 737, 738,
737, 738, 739, 740, 741, 742, 745, 804, 805, 806, 739, 740, 741, 742, 745, 804, 805, 806, 816, 2231
816, 2231, and 2721 Series and 2721 Series

210-720 1 210-657 1
Operating tool, type 3, (5.5 x 0.8) mm blade, with Operating tool, type 1, short, (2.5 x 0.4) mm angled
partially insulated shaft, suitable for blade, with partially insulated shaft, suitable for 218, 233,
745, 746 and 831 Series 234, 235, 250, 253, 730, 733, 734, 735, 739, 713,
714, 805 and 2734 Series
210-721 1 210-648 1

Operating tool, type 1, short, (3.5 x 0.5) mm angled
blade, with partially insulated shaft, suitable for 226, 231,
232, 235, 236, 237, 246, 250, 254, 255, 256, 257,
721, 722, 723, 731, 732, 733, 735, 736, 737, 738,
739, 740, 741, 742, 745, 804, 805, 806, 816, 2231
and 2721 Series

210-658 1

The blade dimensions of the above-listed operating tools The above-listed operating tools with blade dimensions to
are ideal for operating both PCB terminal blocks and DIN 5264 are ideal for operating PCB terminal blocks.
MCS connectors.
