4.2 General Characteristics

 Power supply: 3 x 230Vac -15% … 500Vac +5%, Standard supply configuration
50/60Hz ±2% ADV200 - 4
 Regulation:
 Power ratings: from 4kW to 90kW • 2 bipolar analog inputs (Voltage/Current)
 Max output voltage 0.98 x Vin
• 2 bipolar analog outputs (1: Voltage/Current, 1: Voltage)
 Asynchronous motors control mode:
• 6 digital inputs (PNP/NPN)
• Open-loop vector control
• 2 relay outputs, single contact
• Vector control with feedback ADV200-DC
• RS232 serial line (Modbus RTU)
• Open loop V/f and V/f with feedback
 Power:
 Overload:
• Integrated choke DC side (from size 4300)
• 150% In for 60 seconds every 5 minutes
• Integrated mains filter (≥ size 4300)
• 180% In for 0.5 seconds every 5 minutes
• Integrated dynamic braking module (up to size 5550) ADV200 - 6
 Integration of up to 2 options onboard the drive
 GF-eXpress multi-language programming SW (5 languages)
Options
 IP20-rated protection
 Multilingual programming keypad with LCD screen (5 lines x
 Reference resolution: Digital = 15bit + sign 20 characters) and memory for 5 parameter sets
Analog input = 11bit + sign
Analog output = 11bit + sign  Input choke ADV100
 Output chokes
 Braking resistors
Fieldbus management
 Incremental digital encoder feedback card (EXP-DE-I1-ADL)
CANopen / DeviceNet comunication (integrated into ADV120-
...-C models)  I/O expansion cards
 CANopen / DeviceNet communication (integrated in ADV120- ADV80
® ...-C models)
 External EMC filter (4...45 kW: C2 Category / 1st Environ-
ment / Motor cable length 30m; ≥ 55kW: C3 Category /
2nd Environment / Motor cable length 100m)..
AFE200
Conformity
 Immunity/Emissions: CEE - EN 61800-3

Precision Environmental conditions
Control Speed control accuracy (*) Control  Ambient temperature: -10°C ... +40°C (+14°F ...+104°F),
mode range +40°C…+50°C (+104°F…+122°F) FFE200
FOC with feedback ± 0.01% motor speed rating 1 : 1000 with derating
Open-loop FOC ± 30% motor slip rating 1 : 100  Altitude: Max 2000 m. (up to 1000 m with-
V/F ± 60% motor slip rating 1 : 30 out derating)
(*) for standard 4-pole motor
SMB200

Markings
Complies with the EEC directive
concerning low voltage equipment
Complies with directives for the
American and Canadian markets.
