84 Inverter System & Power Supply Unit
Size 3 227.8 mm (8.97”) 151.2 mm 30.4 mm
13 mm
...480V Power supply
ADV200 - 4 • Basic
387 mm (15.23”)
181.6 mm (7.15”)
Sizes ADV80 Dimensions: Width x Height x Depth Weight
mm inches kg lbs
3150 ... 3220 227.8 x 387 x 181.6 8.97 x 15.23 x 7.15 10.5 23.15
ADV80 • 400V
