Brass Brass Metric Compression

Metric Compression

Parker’s Metric Compression Fittings provide users with an economical choice with numerous connection
options for a wide variety of tube materials without the need for flaring, soldering or other tube
preparation necessary to assemble.

Product Features:
■ 4mm – 28mm tube sizes
■ NPT, BSPT, BSPP, Metric Threads
■ NBR seal
■ Silicone free
Markets: Applications:
■ Factory/Process ■ Air lines
Automation ■ Lubrication Lines
■ Automotive Process ■ Cooling lines
■ Packaging ■ Water
■ Pneumatic ■ Machinery
■ Printing ■ Compressors
■ Fluid transfer
Specifications:

4mm 3335 psi 14mm 652 psi
6mm 2175 psi 16mm 580 psi
Pressure Range 8mm 1450 psi 18mm 536 psi
10mm 1087 psi 20mm 507 psi
12mm 797 psi 22mm 435 psi

Temperature
Range -40˚ to +250 ˚F

Compatible Tubing:
■ Copper
■ Aluminum
■ Thermoplastic tubing

Parker Hannifin Corporation | Fluid System Connectors | Otsego, MI G17
