Page 241 - Brass, Composite and Thermoplastic Fittings and Valves

Catalog 3501E

0118 Single Banjo with Brass Metric Compression
Bi-Material Seal Male BSPP
L1
PART NO. OD C F F1 H H1 MAX L1 N KG 0119 Double Banjo with
0118 04 10 39 4 G1/8 14 10 23 9.5 24 14.5 17.5 .038 Bi-Material Seal Male BSPP
0118 05 10 39 5 G1/8 14 12 23 9.5 25 14.5 17.5 .041 PART NO. OD C F F1 H H1 L1 L2 N KG
0118 05 13 39 5 G1/4 17 12 24 10 26 16 21 .064 0119 04 10 39 4 G1/8 14 10 23 9.5 14.5 24 17.5 .050
0118 06 10 39 6 G1/8 14 13 23 9.5 25 14.5 17.5 .042 0119 05 10 39 5 G1/8 14 12 23 9.5 14.5 25 17.5 .049
0118 06 13 39 6 G1/4 17 13 24 10 26 16 21 .057 0119 05 13 39 5 G1/4 17 12 24 10 126 26 21 .072
0118 08 10 39 8 G1/8 14 14 23 9.5 28 15.5 17.5 .055 0119 06 10 39 6 G1/8 14 13 23 9.5 14.5 25 17.5 .056
0118 08 13 39 8 G1/4 17 14 24 10 28 15.5 21 .058 0119 06 13 39 6 G1/4 17 13 24 10 16 26 21 .071
0118 08 17 39 8 G3/8 22 14 31.5 13.5 30 18 26.5 .113 0119 08 10 39 8 G1/8 14 14 23 9.5 15.5 28 17.5 .072
0118 10 13 39 10 G1/4 17 19 30 13 34 19 23 .118 0119 08 13 39 8 G1/4 17 14 24 10 15.5 28 21 .080
0118 10 17 39 10 G3/8 22 19 31.5 13.5 34 19 26.5 .128 0119 08 17 39 8 G3/8 22 14 31.5 13.5 18 30 26.5 .118
0118 12 13 39 12 G1/4 17 22 33 14.5 34 19 23 .128 0119 10 13 39 10 G1/4 17 19 30 13 19 34 23 .156
0118 12 17 39 12 G3/8 22 22 34.5 15 34 19 26.5 .140 0119 10 17 39 10 G3/8 22 19 31.5 13.5 19 34 26.5 .167
0118 14 13 39 14 G1/4 17 24 36 16 37 20.5 28 .189 0119 12 13 39 12 G1/4 17 22 33 14.5 19 34 23 .180
0118 14 17 39 14 G3/8 22 24 37.5 16.5 37 20.5 28 .198 0119 12 17 39 12 G3/8 22 22 34.5 15 19 34 26.5 .183
0118 14 21 39 14 G1/2 27 24 39 16.5 38 20.5 32.5 .205 0119 14 13 39 14 G1/4 17 24 36 16 20.5 37 28 .248
0118 15 17 39 15 G3/8 22 24 37.5 16.5 37 20.5 28 .389 0119 14 17 39 14 G3/8 22 24 37.5 16.5 20.5 37 28 .247
0118 15 21 39 15 G1/2 27 24 40 16.5 38 20.5 32.5 .202 0119 14 21 39 14 G1/2 27 24 39 16.5 20.5 38 32.5 .262
0118 16 21 39 16 G1/2 27 27 40 16.5 38 21 32.5 .225 0119 15 17 39 15 G3/8 22 24 37.5 16.5 20.5 37 28 .246
0118 18 21 39 18 G1/2 27 30 47 20 43 24.5 36 .369 0119 15 21 39 15 G1/2 27 24 40 16.5 20.5 38 32.5 .251
0118 20 27 39 20 G3/4 32 32 50 20.5 44 24.5 39 .394 0119 18 21 39 18 G1/2 27 30 47 20 24.5 43 36 .469
0118 22 27 39 22 G3/4 32 36 54 22.5 45 24.5 39 .462 0119 20 27 39 20 G3/4 32 32 50 20.5 24.5 44 39 .638
Zinc plated steel with NBR seal 0119 22 27 39 22 G3/4 32 36 54 22.5 24.5 45 39 .610

0119 Double Banjo with 0106 Equal Tube-to-Tube Connector
Captive Sealing Washer Male BSPP L
PART NO. OD F F1 L1 KG
PART NO. OD C F F1 H H1 L1 L2 N KG MAX
0119 04 10 4 G1/8 14 10 24 9.5 14.5 24 17.5 0.049 0106 04 00 4 10 10 28 10 0.016
0119 06 10 6 G1/8 14 13 24 9.5 14.5 25 17.5 0.056 0106 05 00 5 11 12 31 11 0.023
0119 06 13 6 G1/4 17 13 25 10 16 26.5 21 0.038 0106 06 00 6 11 13 32 11 0.026
0119 08 10 8 G1/8 14 14 24 9.5 15.5 28 17.5 0.069 0106 08 00 8 13 14 36 10 0.031
0119 08 13 8 G1/4 17 14 25 10 15.5 28 21 0.074 0106 10 00 10 17 19 42 13 0.070
0119 08 17 8 G3/8 22 14 32 13 18 30.5 26.5 0.140 0106 12 00 12 19 22 42 13 0.092
0119 10 13 10 G1/4 17 19 31 13 19 34 23 0.156 0106 14 00 14 22 24 45 11 0.104
0119 10 17 10 G3/8 22 19 32 13 19 34 26.5 0.165 0106 15 00 15 22 24 45 11 0.097
0119 12 13 12 G1/4 17 22 34 14.5 19 34 23 0.180 0106 16 00 16 24 27 48 13 0.141
0119 12 17 12 G3/8 22 22 35 14.5 19 34 26.5 0.182 0106 18 00 18 27 30 53 14 0.186
0119 14 13 14 G1/4 17 24 37 16 20.5 37.5 28 0.246 0106 20 00 20 30 32 56 14 0.211
0119 14 17 14 G3/8 22 24 38 16 20.5 37.5 28 0.247 0106 22 00 22 32 36 60 14 0.283
0106 25 00 25 36 41 64 14 0.396
0119 14 21 14 G1/2 27 24 40 16 20.5 38 32.5 0.219
0106 28 00 28 41 42 64 14 0.399
Zinc plated steel with NBR seal. Thread with pre-assembled polymer washer
