Catalog PDN1000-3US Actuator Products – Compact Cylinders
Parker Pneumatic LP/LPM Series

LP/LPM Series

• Low profile design
• Flexible construction with special modification
capability
• High density iron rod bearing provides maximum
support for longer life
• Single and double acting versions available
• 6 mounting styles
• 8 bore sizes from 9/16" to 4"
• Strokes from 1/8" to 6" Operating information
• Permanent lubrication Operating pressure: 200 PSIG (17 bar) B
• Non-lube service Temperature range: LP -10°F to 200°F (-23°C to 93°C)
LPM -10°F to 140°F (-23°C to 60°C)
Compact Cylinders Actuator Products
Filtration requirements: 40 micron, dry filtered air

Ordering information

1.50 K N LP L V B E S 9 1.25"

Bore size Series Spring Stroke length
0.56 9/16" LP Standard Blank None Specify stroke
0.75 3/4" LPM Magnetic E Spring length required P1Q Series
1.12 1-1/8" Piston 5 extended in inches.
1.50 1-1/2" R Spring
2.00 2" Piston seal return Rod end thread style
2.50 2-1/2" Blank Standard seal 9 Standard female rod end
3.00 3" L Lipseal piston 4 Optional male rod end P1M Series
4.00 4" seal 3 3 Special rod end
(specify dimensions or
Double rod cylinder Seals sketch)
Blank Single rod Blank Standard LP/LPM Series
K Double rod V Class 5 seals Special features
Blank No special
Mounting style feature
N Basic (Std.) Bumpers* S Special feature
Single rod styles Blank No bumpers
4F Head bolt B Bumpers both ends
4R Cap bolt H Head end only
2F Head trunnion 1 C Cap end only 4 1 Not available on 9/16" bore.
2R Cap trunnion 1 * Please reference catalog 0900P-E, 2 Hollow rods are used on double rod cylinders. All hollow rod
1 Cap pivot eye page E60 for stroke reduction. options require the double rod prefix “K”.
Double rod styles 3 Lipseal piston is not available on LPM Series.
4 Not available on spring extend.
N Basic 5 LPM Series with hollow rod option are not available on the
4R Cap bolt 9/16", 3/4" and 1-1/8" bore sizes.
2F Head trunnion Note: For sensor specifications and part numbers, please refer
Hollow rod styles 1,2,5 to the Electronic Sensors section.
NH Basic
4RH Cap bolt Sensors
2FH Head trunnion For sensors see page B339.

For ordering purposes, when special options or common modifications are requested, the factory will assign a sequential part
number in place of the model number.
