Catalog PDN1000-3US Actuator Products – Rodless Cylinders
Parker Pneumatic gDl Series

gDl aluminum roller guides

High performance cassettes Special cassette types
with lock device
l
Øa
h h h
b b
The locking cassette with star grip Star grip handle dimensions
handle can be stopped at any desired
location on the rail. The clamping Size Øa b h Clamp Part numbers
star grip knob
device does not exert forces on the rail 12 N/A force
B guideways. 15 25 41 19.0 200 FDC15HP-00020000
The clamping device is used in fixtures
which are movable manually, clamping 20 25 49 23.0 250 FDC20HP-00020000
and stop ledgers, feeding of tools 25 32 56 28.0 250 FDC25HP-00020000
and work pieces. Also available with 35 50 83 38.5 350 FDC35HP-00020000
L-ratchet handle. 45 63 101 48.0 750 FDC45HP-00020000
Dimensions (mm), Force (N) with normal manual
tightening.

l-ratchet handle dimensions
Actuator Products
Rodless Cylinders
Clamp Part numbers
end of stroke stop screws Size l b h force L-ratchet handle
12 N/A
15 45 59.5 19.0 200 FDC15HP-00010000
20 45 67.5 23.0 250 FDC20HP-00010000
25 45 71 28.0 250 FDC25HP-00010000
Series
OSP-P
35 63 96 38.5 350 FDC35HP-00010000
45 78 116 48.0 750 FDC45HP-00010000

P1X
The stop screws are scre wed into L11 Order
Series
threads (op tion) on the gui de rails. Size Ød ØD K min. P number
The end of stroke stop ping energy is 12 M5 12 8 15.0 6.0 63504a
reduced by a rubber cap. With guide 15 M5 12 8 16.0 6.0 63504a
rails whe re the L11 is less than the 20 M5 12 8 17.0 6.0 63504a
P1Z
Series
standard minimum, we off set the 25 M6 15 10 20.5 7.5 63505a
mounting hole by half of its diameter. 35 M8 19 13 26.5 9.5 63506a
Note: Customer must drill and tap the holes for the 45 M10 24 16 33.0 12.0 63507a
stop screws. Dimensions (mm)
GDL
Series
gDl accessories
rail mounting screw covers
Cylindrical
screw Order
Size DIN912 Ø D number
12 M3 6 87752a
Ma te ri al: We ar re si stant pla stic, 15 M4 8 87753a
re si stant to oil and aging.
20 M5 10 87754a
Moun ting: Put a pla stic pla te on top 25 M6 11 87755a
and pound in uniform ly.
Remo ve re si du al burrs with 35 M8 15 87756a
a soft brush or fingernail. 45 M10 18 87757a
Dimensions (mm)
Note: Use respective order numbers for ordering
separately or include in rail part number.
